DC 12V to DC 24V 3A 5A 8A 10A 15A Step Up Car Power Converter 12VDC to 24VDC 10AMP 12 Volt to 24 Volt Boost Voltage Regulator
Description
Product description
DC 12V to DC 24V 3A 5A 8A 10A 15A Step Up Car Power Converter 12VDC to 24VDC 10AMP 12 Volt to 24 Volt Boost Voltage Regulator
Specification |
|
Product Name |
12V to 24V 2A 3A 5A 8A 10A 12A 15A DC DC Converter |
|
Brand Name |
Fulree |
|
Model No. |
122402/122403/122405/122408/122410/122412/122415 |
|
Module Properties |
non-isolated boost module |
|
Rectification |
synchronous rectification |
|
Input (cable length: 12cm) |
|
|
Input Voltage |
DC 12V |
|
Input Voltage Range |
DC 10-20V |
|
Output(cable length: 12cm) |
|
|
Output Voltage |
DC 24V |
|
Output Current |
2A /3A / 5A / 8A / 10A /12A / 15A Max |
|
Output Power |
48W / 72W / 120W / 192W / 240W / 288W / 360W Max |
|
Conversion Efficiency |
>93% |
|
Voltage regulation |
±1% |
|
Load regulation |
± 2% |
|
Ripple (Full load test) |
< 150mV |
|
No-load current |
<60mA |
|
Working Temperature |
-40~80℃( If ambient temperature exceeds 40°c, lower power use, or to enhance heat dissipation) |
|
Waterproof Rating |
IP68 |
|
Protection |
Over-current protection / Overheating protection / Over voltage protection / waterproof IP68 design, anti-shock protection |
|
Application |
mobile phone, car camera, Electric motors, Trucks, Golf Carts, Forklift, Solar Panel Power System, water pumps, industrial equipment and so on. |
|
Case Material |
Die-casting aluminum alloy |
|
Product Size (L x W x H) |
74*74*32mm |
|
Product Weight |
280g |
|
Warranty |
12 months |
|
Cooling Way |
Free air convection |
|
OEM&ODM Service |
Acceptable |
