Customized Wood Pellet Machine: Exploring Ring Die, Wood Pellet Pressing Die, and Matrix Technologies
Description
产品描述
我们公司溧阳市泽吉机械有限公司是一家专业制造商，专注于：锤式粉碎机、搅拌机、饲料/木屑颗粒机、冷却器、破碎机、筛分机、挤出机、干燥机、包装机、加液机、输送机和备件：木材削片机飞刀、锤式粉碎机刀片/筛网、环模、滚筒和其他颗粒机的备件。
对于机器，我们有自己的激光切割机、CNC 加工中心、焊接机。对于环模，我们拥有自己的自动枪钻机（12 台）、自动锪孔机、自动车床、真空热处理机。
我们坚持高品质和有竞争力的价格，寻求长期业务和双赢。
XGJ560 XGJ850 XGJ630 wood pellet machine ring die pellet die matrix mold
Range of ring die spare parts' Application
Applicable for Biomass pellet machine: wood pellet mill, sawdust pellet mill, grass pellet mill, straw pellet mill, crop stalk pellet machine, alfalfa pellet mill etc.
Applicable for Fertilizer pellet machine, all kinds of animal/poultry/livestock feed pellet machine too.
Process for making pellet mill ring dies
Blank raw material Forging---Rough turning---Half finished turning---Drilling the hole---Grinding inner bore---Treaded hole--- Keyway milling---Heat treatment---Finish turning---Package
Introduction of pellet machine ring die
1. Material of the ring die: X46Cr13 /4Cr13(stainless steel), 20MnCr5/20CrMnTi (alloy steel) or customized
2. Hardness of ring dies: HRC54-60.
3. Diameter of ring die can do: 1.0mm up to 28mm
4. Pellet die type can do: Ring Die or Flat Die
5. Outer diameter can do: Outer diameter up to 1800mm
6. Pellet Die model we can customize:
For Awalia pellet mill: Awalia 420, Awalia350, etc
For Buhler pellet mill: Buhler350, Buhler400, Buhler420, Buhler520, Buhler660, etc.
For CPM pellet mill: CPM2016, CPM3016, CPM3020, CPM3022, CPM7726, CPM7932, etc.
For CPP pellet mill: CPP150, CPP200,CPP360,CPP300,CSP020, etc.
For IDAH pellet mill: IDAH530, IDAH530F, IDAH635D, etc.
For Muyang pellet mill: MUZL180, MUZL350, MUZL420, MUZL600, MUZL1200, MUZL610, MUZL1210, MUZL1610, MUZL2010; MUZL350X, MUZL420X, MUZL600X, MUZL1200X(Especially for shrimp feed pellet, diameter: 1.2-2.5mm)
Muyang FAMSUN350,Muyang FAMSUN420, Muyang FAMSUN550, Muyang FAMSUN600, Muyang FAMSUN1210
For Zhengchang feed pellet mill: SZLH250, SZLH300,SZLH320,SZLH350,SZLH400,SZLH420,SZLH508, SZLH678, SZLH768, etc
For HKJ feed pellet mill: HKJ250, HKJ320,HKJ350,HKJ400,HKJ420,HKJ508 etc
For SZLJ feed pellet mill: SZLJ250, SZLJ320,SZLJ350,SZLJ400,SZLJ420,SZLJ508 etc
For OGM pellet mill: OGM-0.8, OGM-1.5, OGM-6, etc
For VAN ARSEN pellet mill: Van Arson C600, Van Arsen750, Van ArsenC900, etc
For KAHL pellet mill (Flat die): KAHL38-780, KAHL37-850, KAHL45-1250, etc
For PTN pellet mill: PTN580, PTN580-C, etc
For Yemmak pellet mill: YEMMAK520, YEMMAK420, etc
For Zhengchang wood pellet mill: MZLH250 ,MZLH320, MZLH350, MZLH400, MZLH420, MZLH508, MZLH678, MZLH768, etc
For Yulong wood pellet mill: XGJ560, XGJ850, etc
Pls let us know below information to customize for you:
| 1.What is your ring die model? | We can customize the model as you need |
| 2.What is the metaril you need? | Stainless steel or alloy steel can produce |
| 3.What hole size you need? | We can make 1-20mm hole |
| 4.What is the delivery time? | Usually 10-30 days. |
