electric label sewing machine for automatic sewing
Contact Now
Description
Product description
Product Description
- the over lock sewing machine applied to sew all kinds of jeans, knitted fabric.
- High speed sewing and exquisite lines for high productivity, sewing speed can reach 3200rpm.
- The work clamp lifter height can be adjusted by the digital operation panel.
- line-off and bird's nest prevention system
- New technology design for low power consumption, low noise, low vibration
- The system is compatible with Brother sewing machine
Specification
| Model | CC-430D-01S | CC-430D-02S | CC-438D |
| Sewing area | Max.4×3cm | Max.4×3cm | Max.6.4×6.4cm |
| Highest sewing speed | 3200rpm | 3200rpm | 2700rpm |
| Line | single needle sewing | ||
| Feeding device | Intermittent feeding (pulse motor driven mechanism) | ||
| Stitch length | 0.05-12.7mm | ||
| Max.stitches | 210,000 stitches | ||
| Work clamp lifter | pnuematic (height:max.30mm) | ||
| Clamp lifter | all in one | ||
| Clamp lifter ascensional range | 17mm | ||
| Hook | semi-rotating shuttle | ||
| Tension device | standard tension device | ||
| Data storage | USB or Memory card(CF card can save and edit any sewing patterns) | ||
| Patterns | 89 patterns inside the machine, up to 200 patterns, total 200,000stitches | ||
| Motor | AC servo motor 550W | ||
| Air pressure | 0.5Mpa 1.8L/min | ||
| Net weight | 160kg | ||
| Gross weight | 208kg | ||
| Packing | 125*85*135cm | ||
| CBM | 1.44m³ | ||
