JKW-15: Affordable 1000Kg Mini Excavator - 1.8 Ton Digger Machine
Contact Now
Description
产品描述
JKW-15 mini hydraulic excavator has beautiful design, its platform can rotate 360 degrees. This is a multifunctional and efficient excavator, Bucket Capacity is 0.03m³, Operating Weight is 1280kg, MAX. Digging Depth is 1.6m. Very flexible, even in a small working environment, it can achieve maximum performance. And the weight and volume are small and convenient for transportation. It can be moved quickly from one place on the job site to another, so you can use this mini excavator to complete more tasks in a shorter time.In order to reduce operating costs, TE15 mini excavator is equipped with an efficient hydraulic system. And this mini excavator is equipped with rubber tracks, which is not easy to damage the ground, reliable and easy to use.
|
JKW-15 Excavator
|
|
|
|
|||
|
Bucket Capacity
|
0.03m³
|
发动机
|
LAIDONG / YANMAR
|
|||
|
Chassis Width
|
1100mm
|
Engine Power
|
18.1kw/2200rpm 10kw/2200rpm
|
|||
|
Track Length
|
1350mm
|
Turning Radius
|
1600mm
|
|||
|
Chassis Ground Clearance
|
115mm
|
Max.Digging Height
|
2850mm
|
|||
|
Gradeability
|
35°
|
Max.Dumping Height
|
2030mm
|
|||
|
Track Width
|
180mm
|
Max.Digging Depth
|
1600mm
|
|||
|
Volume of fuel tank
|
15L
|
Max.Digging Radius
|
2500mm
|
|||
|
Transport Length
|
2900mm
|
Max.Vertical Digging
Depth |
1400mm
|
|||
|
Excavator Height
|
1550mm
|
Bucket excavating force
|
11kN
|
|||
|
Overall Dimension( LxWxH)
|
2900*1100*1550mm
|
Weight
|
1500kg
|
|||
|
Multi-way Valve
|
Traveling Motor
|
Swing Motor
|
Tianji Hydraulic Pump
|
|||
