0-63m/Min Hoist Construction Elevator
Description
产品描述
SC2
| Technical parameters |
Unit |
SC200/200 (0-63m/min) | |
| Height | m |
300 |
|
| Rated load | kg | 2000/2000 | |
| Maximum capacity | 9 /9 | ||
| Boom lift wweight | kg | ≤200 | |
| Lifting speed | m/min | 0-45 | |
| Electormotor | Model | YZEJ132ML-4 | |
|
Power |
kw | 15*2 / 15*2 | |
| Speed-limiter | Model | SAJ40-1.2A | |
| Rated tripping speed | m/s | 1.2 | |
| Standard motion speed | m/s | 1.1 | |
| Rated automaticload | KN |
40 |
|
| Type | gradual | ||
| Reducer | Model | SWC1 | |
| Center distance | mm | 125 | |
| Speed radio | 1:12 | ||
| Bracking distance | m | 0.3-1.2 | |
| Max lnclination of frame | angle | 0-15 | |
| Mast section dimension | mm | 650×650×1508 | |
| Crane cage inner net dimension | m |
3.2*1.5*2.2 |
|
| Guardrail dimension | m |
5.93*3.62*1.82 |
|
| Hoistway dimensions | m | ||
| Free end height of the guide rail frame | m | ≤4.5 | |
| Gounterweight weight | kg | 1100 | |
| Direct attached frame | Installing interval | m/set | 4.5 |
| Distance between two embedded parts | mm | 1488 | |
| Installation dimensions from center of rail frame to building wall | mm | 2800-3200 | |
| Safe and protection system | Upper and below limited switches,upper and below limit utmost switches,gate limited switch,falling avoiding safe device,cushion device,safe lock of gate,counterweight rope breaking or loose protecting device,safe hook,The safety device against overload,Anti-punching standard section etc. | ||
China FYG SC200/200 Inclined construction elevator Curved or Inclined Surface Building Hoist elevator lifter construction elevator elevator lift construction build lifter
Taking construction technology to the next level is our mission – and that means making it cost-efficient, accurate, future-proof and connected. We are a market and technology pioneer in construction machinery. Our product include:
concrete mixer and concrete batcher is the main components of the Concrete batching plant , used for mixing concrete.；
Tower cranes are used to lift heavy objects on construction sites；
Construction elevator is used for both manned and cargo;
concrete pump are used to transport concrete on site;
stabilized soil mixing plant is used to produce cement stabilizer for highway ;
The main purpose of the concrete mixing truck is to transport the concrete or mortar that has been mixed in the concrete mixer to the construction site
Screw conveyor is used for trsport cement from cement silo to mixer
