Hot Sale High-Speed Toothbrush Making Machine: Best Quality and Price
Description
产品描述
Product Description :
This machine is suitable for all kinds tooth brush of the diameter from dia1.2mm-3.0mm and within the height of bristle is 20mm for tufting.
Bored with one tufting head, high-speed processing, high-volume, cost-effective.
Panel control system of man-machine, Chinese or English display, simple to understand
Wearing parts and spare parts are standardized designs to reduce hair mechanic technology dependence;
Hair by: flat style.
Largest wool length: 20mm
Models can be stored: 2000
Input methods: Chinese or English display, menu-driven operation, handheld encoder or key board input.
Technical parameters
|
description |
unit |
parameters |
|
Max speed |
Holes/min |
≤750 |
|
Max speed |
Piece/h |
1000 |
|
Hole diameter |
mm |
1.2-3.0 |
|
Axis quantity |
axis |
2+2 |
|
Journey X axis |
mm |
48 |
|
Journey Y axis |
mm |
25 |
|
Maximum program quantity |
piece |
2000 |
|
Air pressure |
Mpa |
0.6-0.8 |
|
Power voltage, frequency |
V,Hz |
220,50 |
|
Machine power |
KW |
3 |
|
Contour size |
mm |
1400*1250*1250 |
|
weight |
KG |
750 |
|
Control system |
CNC controller |
|
Disturbance display |
English edition |
|
Safety protection |
Overload, short circuit protection |
|
Lubrication |
Auto lubrication system |
|
Main speed control |
Frequency inverter |
|
Fiber box |
Two or Three colors box |
