Product ID: 68072802
YOAO Plasma Cutter and Welding Machine - 1ph 220v 3ph 380v Cut 100
Contact Now
Description
Product description
Products Description
|
Technical data
|
Unit
|
CUT-80
|
CUT-100
|
CUT-120
|
CUT-160
|
|||
|
Rated input Voltage
|
V
|
220(1PH)/380(3PH)
|
|
|
|
|||
|
Rated input Power
|
KVA
|
18
|
20.4
|
21.4
|
31.2
|
|||
|
Output Current Range
|
A
|
25-80
|
25-100
|
30-120
|
25-160
|
|||
|
Duty Cycle
|
%
|
60
|
60
|
60
|
60
|
|||
|
Arcing Mode
|
-
|
High frequency-pilot arcing
|
|
|
|
|||
|
Air Pressure
|
KGF/CM2
|
0.3-0.6
|
0.3-0.6
|
0.5-0.6
|
0.5-0.6
|
|||
|
Quality Cutting Thickness
|
MM
|
0.5-15
|
0.5-20
|
0.3-35
|
0.3-45
|
|||
|
Extreme Cutting Thickness
|
MM
|
25
|
30
|
45
|
55
|
|||
|
Machine Dimensions
|
MM
|
470*250*420
|
580*300*550
|
580*300*550
|
620*330*600
|
|||
|
Net Weight
|
KG
|
24
|
26
|
30
|
35
|
|||
