1. Equipped with a pump, the pressure needed to reach 8 kg. 2. Put the ultrasonic generator under the working table, plug cords with the generator and turn on the power. Press the testing button to check if the ultrasonic system is working well. If it is normal, the pointer of bottom panel indicate 0% and the pointer of upper panel indicate between 0% to 20%. 3. Connect the air source, the tube is 8 mm standard endotracheal tube. Access port on the side of two white bottles on the bracket of machine, turn on the air source switch. 4. Put the material on the right welding position, then press the treadle switch of the machine to check the fixing result. If the fixing result is not firm then need to clockwise rotate the delayer inside the generator to delay the welding time of machine. If find the material welded perforated break phenomenon, it means the welding time is too long, then need to counterclockwise rotate the delayer inside the generator to shorten the welding time of machine.
EN
Language
All categories
Product ID: 68119416
Digital Ultrasonic Spot Welding Machine for Pneumatic Power Face Mask Making Machine (Price Included)
Contact Now
Description
Product description
Product Overview
FEATURES AT A GLANCE
Introduction to finished products
Apply on non-woven bags,
Velcro welding,
disposable masks,
lingerie bra welding,
welding of chemical fiber fabrics such as bamboo charcoal package sealing.
Its design is beautiful and easy to operate ,high efficiency capabilities.
non-woven bags
Bamboo charcoal bag sealing
Welding at the interface
PRODUCT SPECIFICATIONS
|
Brand
|
AH
|
model
|
AH-50Q Ultrasonic spot welder
|
|
Working power supply
|
220V 50/60hz 6A
|
Frequency
|
20KHz
|
|
Welding speed
|
30-200 times/minute
|
Output power
|
2000W
|
|
Trial width
|
10-90mm
|
Matching pattern
|
Die
|
|
Driving form
|
pedal
|
automaticity
|
semi-automatic
|
|
gross weight
|
115KG
|
Net weight
|
60KG
|
|
Package size
|
1260*600*1260mm
|
Overall dimension
|
1200*550*1000mm
|
PRODUCT CONFIGURATION
