Wood Chips Biofuel Machinery / Disc Chipper With Electric Control System Lypx Series
Description
Product description
Wood Chips Biofuel Machinery / Disc Chipper With Electric Control System LYPX Series
|
Model |
LYPX116A |
LYPX1710 |
LYPX1212 |
LYPX1216 |
|
Knife Dis Diameter(mm) |
630 |
950 |
1220 |
1600 |
|
Knife Disc Speed(rpm) |
800 |
980 |
740 |
625 |
|
Number Of Knives(pc) |
3 |
6 |
6 |
6 |
|
Length of Wood Chips(mm) |
15-25 |
12-35 |
20-35 |
20-35 |
|
Type of Feeding |
Horizontal |
Incline |
Incline |
Incline |
|
Capacity(m3/h) |
2-3 |
8-12 |
15-20 |
25-45 |
|
Main Motor Power(kw) |
22 |
55 |
90-110 |
220 |
|
Max Dia of Logs(mm) |
100 |
100 |
200 |
300 |
|
Type of Discharge |
Up |
Up |
Up /Bottom |
Up / Bottom |
|
Weight(kg) |
827 |
2665 |
4585 |
8732 |
|
Overall Dimension (L×W×H)(mm) |
2340×1200×1845 |
2550×1600×1650 |
3100×1340×1715 |
3756×1855×2093 |
The series of disc chippers is made up of seat, cutter disc, feed inlet port, shell, electric control system, etc.
This series disc chipper is of compact structure, convenient operation and maintenance, higher production, higher acceptance wood chips, lower consumption. It is the ideal equipment for producing high-quality wood chips
In order to meet the different demands of chips length for different consumers, chip length can be adjusted in a certain range. It has horizontal and slope two types of charge-in methods. The discharging methods also has upper and bottom two types for user’s choosing. The cutter disc adopts wear-resisting chromium plated, greatly prolong the service life.
