High-Quality Drum Wood Chipper Machines: 110KW, 132KW, 8-20 Ton Per Hour Capacity
Description
Product description
Our company Liyang Zeji Machinery Co., Ltd. is a professional manufacturer focus on: hammer mill, mixer, feed/wood pellet machine, cooler, crumbler, screener, extruder, dryer, packing machine, liquid adding machine, conveyors and spare parts: wood chipper fly-knives, hammer mill blades/screen, ring die, roller and other pellet machines’ spare parts.
For machines, we have own laser cutter, CNC machining center, welding machines. For ring die, we have own auto gun-drilling machines (12 sets), auto counter-sinking machines, auto lathing machines, vacuum heat treatment machines.
We insist on high quality and competitive price, looking for long term business and win-win.
BX Wood Chipper
1.Features
1.1.The engine of wood chipper, welded by high strength sheet metal, is the support foundation for the whole machine.
1.2.Dead-knife seat support welded with the engine base is used to put the knife seats.
1.3.The pressed block fasten the dead knife in the knife seats by specialized in manufacturing of high strength bolts.
1.4.The knife base is fixed in the engine base by clamp which can pass through the hole of side wall of base free.
1.5.The chips can fall down through the screen and discharge the bottom of engine base.
1.6.Oversized wood chips can be broken by grinding rod installed in the engine base.
|
Technical parameters/ Model |
BX216 |
BX218 |
BX218D |
BX218-11 |
|
Diameter of cutters' roller(MM) |
650 |
800 |
800 |
800 |
|
Feeding size(HXW) |
180X500 |
225X680 |
240X750 |
240X1050 |
|
Quantity of fly-cutters(PCS) |
2 |
2 |
2 |
3X2 |
|
Speed of cutters' roller(RPM) |
590 |
650 |
650 |
650 |
|
Feeding speed(M/MIN) |
37 |
38 |
38 |
39 |
|
Max diameter of logs(MM) |
120 |
160 |
160 |
for board |
|
Capacity(M³/H) |
10 |
22 |
38 |
30 |
|
Chips size(MM) |
30 |
30 |
30 |
20 |
|
Main motor power(KW) |
55 |
110 |
132 |
160 |
|
Feeding roller power(KW) |
3X2 |
4X2 |
4X2 |
5.5X2 |
|
Pump power(KW) |
Manual pump |
0.55 |
0.55 |
0.55 |
