High Glossy PVC / HPL / UV/Melamine Paper Coated MDF
Description
Basic Info.
- Model NO. HL-658
- Finish Melamine Impregnated Paper
- Formaldehyde Emission Standards E0, E1, E2
- Usage Indoor
- Production Process Dry-Proces
- Size 1220mm*2440mm, 1830mm*2440mm
- Thickness 2.0mm-30mm
- Certification BS, CARB, CE, ISO
- Surface Matt Pitting, Textured, Light, Embossed, High Glos
- The Weight of Melamine Paper 85g-110G/M2
- Application Furniture, Decoration, Office
- Materials Poplar, Hardwood
- Melamine Paper Solid Colour, Woodgrain Colour, Marble etc
- Transport Package Strong Seaworthy Wooden Pallet Packing
- Specification 1830mm/1220mm*2440mm*2.0mm-30mm
- Trademark HUNGLIN MDF
- Origin Shandong, China
- HS Code 44111
- Production Capacity 80000cbm/Year
Product Description
Product name: Raw MDF, Plain MDF, Melamine MDF, Veneer MDF, HPL MDF
Thickness: 2mm - 35mm
Size: 1220*2440*2-25mm, 1830*2440*2.7/3/8/12/16/18mm, 1830*2750*9-25mm, (1830+610)*3660*8/12/16/18/25mm, 1220*2800*12/16mm, 1300*2800*6/8/17/18mm, 2070*2440*4.5/7/11/13/16mm, 2070*2800*4.5/5/7/8/11/13/16mm; 2200*2800*5/8/12/16/18/25mm etc
Color and Material: 100% poplar material with white color; 100% pine material with light yellow color; 70% poplar or 70% pine mix 30% hard wood with normal color
Glue: E2, E1, E0
Density: >730KGS/M3 for 7-25mm, >820KGS/M3 for 2.0-6mm
Face/back: Plain, Melamine paper, wood veneer, UV coat, HPL
Surface treatment: Matt, textured, glossy, light, embossed or magic
Color: Solid colors, wood grain colors, fancy colors, stone colors
Veneer: Natural / engineered walnut, okoume, sapeli, beech, red oak etc
Material: Poplar, pine, hardwood, combi
Performance:
- Density even, surface smooth, easy for machining and shaping
- Made of meticulous fiber, no sharp wood grain
- Easy for oil painting
- Sideboard of MDF is smooth and neat, not rough after sawing
- Hard to be out of shape
- Toxic gas emission is tightly controlled well
Usage: Furniture, construction, decoration, Carving, counter, office table, ceiling, packing etc
Certificate: CARB, FSC, CE, ISO9001:2000, ISO14001
Main market: Middle East, Latin America, Asia, Africa
Quantity: 20' container (pallet packing) 8pallets/22CBM; 20' container (loose packing) 26CBM; 40' container (pallet packing) 16pallets / 43CBM
Payment Terms:
- Irrevocable L/C at sight
- T/T, 30% as deposit, the remaining 70% to be paid against the copy of B/L
Delivery Time: Within 15 days after receiving deposit or original L/C
Physical Properties
| No. | Test Items | Technical Specification | Unit | Test Result |
|---|---|---|---|---|
| 1 | Moisture Content | 4~13 | % | 5.8 |
| 2 | Density | 450~880 | Kg/m3 | 730 |
| 3 | Density Tolerance | ±7.0 | % | ±1.4 |
| 4 | Expansion ration in thickness due to water absorption | ≤10 | % | 7.0 |
| 5 | Internal bonding | ≥0.45 | Mpa | 0.60 |
| 6 | Modulus of rupture | ≥20 | Mpa | 26.8 |
| 7 | Modulus of elasticity | ≥2200 | Mpa | 3280 |
| 8 | Screw holding | Face≥1000 | N | 1300 |
| Side≥800 | 960 | |||
| 9 | Surface bonding | ≥1.2 | Mpa | 1.45 |
| 10 | Formaldehyde Emission | E1: ≤9.0 | mg/100g | 4.9 |
| E2: ≤30.0 | 15 |
Company Introduction
Hunglin Wood is a wood-based panel products company serving the industrial and building materials markets. The main products are commercial plywood, film faced plywood, furniture, Melamined board, slotted mdf board, UV mdf and other wooden boards. Our company was established in 2015, and we have many years of experience in the wood industry.
Our company employs more than 50 workers, and through the efforts of our entire workforce, we have become a strong wood manufacturer who are continuously working toward improving product quality. Our company has always focused on research, development and innovation. Aiyang believes in reasonable prices, efficient production time and good after-sales service. We hope to cooperate with more customers in the future and welcome all potential buyers to contact us.
