QianJiao p200 pro
Description
Core Product Positioning
-
Product Type: Industrial-grade tethered Remote Operated Vehicle (ROV).
-
Target Users: Government agencies, scientific research institutions, and enterprises for professional underwater operations.
-
Design Philosophy: Simple | Powerful.
Core Performance Parameters
-
Dimensions & Weight: 608x294x196 mm (excluding fill light), approximately 8 kg.
-
Max Diving Depth: 200 meters.
-
Operating Radius: 400 meters (expandable via customizable cable length).
-
Max Speed: 3 knots.
-
Thrust: Forward 5.7kg / Upward 4.0kg / Sideways 3.6kg.
-
Endurance: >4 hours (at set depth, lights off).
-
Operating Temperature: -10℃ to 45℃.
Key Technological Upgrades & Features
-
Modular Quick-Release System
-
Features a slide-groove mounting platform and quick-release technology, enabling tool-free installation/removal of over 20 accessories (e.g., sonar, positioning systems, water samplers).
-
Integrates 5 accessory interfaces, supporting up to 5 accessories operating simultaneously, streamlining multi-mission integration.
-
-
Second-Generation Anti-Sand Motor (C-MOTOR 2.0)
-
Utilizes new materials, processes, and fluidized design, increasing power output by 30%. Significantly enhances sand-clogging resistance, is easier to clean, and offers greater reliability.
-
-
Shore-Based Power Supply System (C-SPSS)
-
Battery compartment design for easier installation.
-
Output power increased to 1500W, ensuring uninterrupted operation for the ROV during full-power missions, enabling 24/7 continuous operation.
-
-
Professional Lighting System
-
External 8000-lumen LED fill light with dual light sources and a 150° optimal illumination angle, effectively reducing visual interference from floating object reflections.
-
Supports 0-100% stepless brightness adjustment. Lights are flexibly foldable to adapt to various underwater scenarios.
-
-
Imaging & Recording System
-
Capable of 4K/30fps HD video and 12-megapixel photo capture.
-
Built-in 128GB SD card (expandable up to 512GB), plug-and-play for convenient data download anytime, anywhere.
-
-
Open Ecosystem for Accessories & Software
-
Supports a wide range of high-end dedicated accessories (e.g., ranging sonar, Doppler Velocity Log DVL, water quality detectors, Ultra-Short Baseline USBL positioning, 3D imaging sonar).
-
Compatible with third-party hardware and software, offering strong expandability.
-
Typical Application Scenarios
-
Underwater Emergency Rescue
-
Ship Dock & Port Inspection
-
Aquaculture Monitoring
-
Hydropower & Water Conservancy Project Inspection
-
Underwater Scientific Exploration
-
Offshore Wind Turbine Inspection
