8-32 10-32 4-40 round Fasteners 304 Steel and Stainless Steel Wire Thread Inserts Box and Carton Packing
Description
304 wire thread insert 8-32 10-32 4-40
| Xiyangyang Steel Wire Sleeve Operating Parameters Table | |||||
| Thread specification d*p |
Nominal length k*d |
Hole depth t2(mm) |
Drill diameter do(mm) |
External Diameter in Free State Dz(mm) |
Cycle number N(≈) |
| 4-40 | 1D | 5.4 | 3 | 3.66-4.04 | 3.0 |
| 1.5D | 6.8 | 4.9 | |||
| 2D | 8.2 | 6.8 | |||
| 8-32 | 1D | 7.3 | 4.4 | 5.20-5.56 | 3.8 |
| 1.5D | 9.4 | 6.1 | |||
| 2D | 11.5 | 8.4 | |||
| 10-32 | 1D | 8.0 | 5.0 | 5.99-6.50 | 4.3 |
| 1.5D | 10.4 | 6.9 | |||
| 2D | 12.8 | 9.5 | |||
Why choose us?
1. We are a factory, directly facing customers, and the price is advantageous
2. We have been engaged in thread nesting for 20 years and have rich production experience
3. Our company has complete qualifications, military quality and first-class product quality
4. We use high-quality source wire materials, with more than 8 nickel content, and a material report can be provided for each batch
5. Our products have high thread precision (5H), standard teeth, and beautiful appearance
6. Our products are complete in size and support customization
7. Supporting installation tools, one-stop shopping
8. Fast delivery
9. Professional after-sales support to help you solve the problems encountered in installation
10. We are online 24 hours a day, and you are always welcome to consult
