Automatic Concrete Pipe Steel Cage Welding Machine
Contact Now
Description
Product description
Spun concrete pipe cage welding machine adopt foreign equipment of advanced structure, electrical automation control action, full digital control circuit welding, using push bar, fully automatic digital continuous variable diameter, frequency conversion speed synchronization, ring stiffened and pitch of arbitrary adjustable.
| main parameters | PGHJ /CPGHJ |
| Diameter of pipe | 300~3000mm |
| Length | 1000~4000mm |
| Diameter of longitudinal bar | 4~6m,8~12mm |
| Spiral wire | 3~6mm |
| PC wire | 12,18,24,32,36,48 |
| Pitch | 40~160mm adjust |
| Welding way | Single round or nugget |
| Power | 75-200KVA |
| Speed | 3-10min/pcs |
| Code | 480,812,1216,1620,2024 |
| Weight | 5~15T |
