LCD PCB FPC TAB ACF Attachment Machine
Contact Now
Description
Product description
Application:
The machine is used for tacking ACF onto LCD glass substrate during LCM production and repair line. It is applicable to various c7 inch LCD panels.
■High precise micrometer adjust work table, which ensure the adjusting accuracy.
■Equiped with advanced PLC controller and colorfull human-machine operation interface, instant temperature curve display.
■High flexibility temperature feedback system can testing, rectifing and compensating temperature instantly, ensure temperature accuracy.
■Precise ACF auto rolling and cutting system, ensure ACF tacking accuracy.
■PLC program controller ensure the stability of machine, which can store 120 sets function parameters, makes the production conveniently.
■Auto-counting function make production control easily.
■Applicable to single and double-layers ACF protective removing, cutting and tacking, are widely used for LCD, PCB and FPC substrate.
■Accessories of machine: Imported and national brand slide rail, bearing, motor and other pneumatic components ensure the accuracy and stability of the machine.
Technical Parameter
Adjusting Time: 0.1S~99S
Operation Interface: Touch Panel
Work Mode: In-out work
Temp Accuracy: ±1℃
Temp Range: RT~399℃
Heat Mode: Constant Heat
Safety Protection: Double buttons
Gas Source: 0.3~0.8Mpa Airpipe Outer ￠8
Voltage: AC220~240V 50Hz
Power: 0.75KW
Dimension: (L)530×(W)600×(H)470mm
Weight: approx. 85KG
The machine is used for tacking ACF onto LCD glass substrate during LCM production and repair line. It is applicable to various c7 inch LCD panels.
■High precise micrometer adjust work table, which ensure the adjusting accuracy.
■Equiped with advanced PLC controller and colorfull human-machine operation interface, instant temperature curve display.
■High flexibility temperature feedback system can testing, rectifing and compensating temperature instantly, ensure temperature accuracy.
■Precise ACF auto rolling and cutting system, ensure ACF tacking accuracy.
■PLC program controller ensure the stability of machine, which can store 120 sets function parameters, makes the production conveniently.
■Auto-counting function make production control easily.
■Applicable to single and double-layers ACF protective removing, cutting and tacking, are widely used for LCD, PCB and FPC substrate.
■Accessories of machine: Imported and national brand slide rail, bearing, motor and other pneumatic components ensure the accuracy and stability of the machine.
Technical Parameter
Adjusting Time: 0.1S~99S
Operation Interface: Touch Panel
Work Mode: In-out work
Temp Accuracy: ±1℃
Temp Range: RT~399℃
Heat Mode: Constant Heat
Safety Protection: Double buttons
Gas Source: 0.3~0.8Mpa Airpipe Outer ￠8
Voltage: AC220~240V 50Hz
Power: 0.75KW
Dimension: (L)530×(W)600×(H)470mm
Weight: approx. 85KG
