PCB Manufacturing and Assembly
Description
Key features include blind and buried vias, V-cut routing for easy panel separation, peelable solder mask options, conformal coating services, and robust surface treatments that ensure durability under harsh environmental conditions. Our state-of-the-art facility houses three SMT lines, two DIP lines, and two assembly stations capable of producing up to 2 million SMT points daily and 300,000 through-hole components per day. Our skilled engineers and automated testing protocols guarantee consistent quality, reduced defect rates, and faster time-to-market for your electronics project.
From initial design review to final inspection, we offer end-to-end support: PCB layout verification, component sourcing, surface mount technology (SMT), through-hole assembly (THT), functional testing, and packaging. This comprehensive approach allows you to focus on innovation while we handle the technical execution. Our clients benefit from flexible customization options, competitive pricing, and strict adherence to international standards such as ISO9001 and CE certification.
These capabilities make our PCB and PCBA services ideal for applications requiring reliability, compactness, and performance—such as smart home devices, automotive control modules, industrial communication equipment, and energy-efficient lighting systems. Whether you're developing a new IoT device or scaling an existing product line, our global-ready solutions adapt to diverse market requirements and regulatory frameworks.
Customers consistently praise our responsiveness, attention to detail, and ability to deliver complex multi-layer boards with minimal turnaround time. Many have highlighted how our engineering team helped refine their original schematics into manufacturable designs, reducing cost and improving functionality without compromising quality.
