Galvanized Channel Steel
Contact Now
Description
Product Introduction
Galvanized Channel Steel is a C-shaped structural steel processed by hot-dip galvanizing, renowned for its superior corrosion resistance and load-bearing capacity. Widely applied in building frameworks, industrial equipment bases, bridge supports, and heavy machinery installations, it is particularly suitable for marine climates and chemical plants, offering a cost-effective solution for global engineering projects.
Construction: Factory building beams, warehouse racking systems, curtain wall supports
Machinery: Conveyor tracks, injection molding machine frames, automation equipment frameworks
Transportation: Bridge reinforcements, highway noise barrier brackets
Energy: Wind turbine towers, power line support channels
Marine: Deck stiffeners, dock support structures
Advantages & Features
▪︎ Extreme Weather Resistance: 30-year zinc coating lifespan, operable in -50℃ to 150℃
▪︎ High Structural Strength: Yield strength ≥235MPa with 35% enhanced bending resistance
▪︎Modular Design: Pre-punched holes (20mm/50mm spacing) for rapid assembly
▪︎ Eco-Certified: Compliant with RoHS, REACH, and ISO 14064 carbon footprint standards
Functions & Characteristics
▸ Surface Treatment: Hot-dip galvanized + trivalent chromium passivation (EU eco-standard)
▸ Manufacturing: Fully automated continuous rolling, sectional tolerance ±0.5mm
▸ Processability: Compatible with laser cutting, welding, cold bending (min. bend radius R=4t)
▸ Quality Assurance: Batch-wise SGS material reports & coating thickness certificates
