China's 8T Flat Top Tower Crane Qtz125 (6015) - 50m Height and 8 Ton Capacity: Gearbox Engine Motor Pump Construction Equipment
Contact Now
Description
Product description
Product Overview
TC6013-6S
flat-top tower crane has a maximum lifting capacity of 6t and an industry-leading lifting speed of 100m/min; it
has a rich combination of boom lengths, with a maximum lifting arm length of 60m, a variable arm length of 5m, a minimum arm
length of 30m, and seven combinations of arm lengths. 4 major institutions have been fully accelerated to improve the overall
efficiency by 35%. Adopting patented jacking safety technology, triple protection of jacking height against topping, double
protection of amplitude against collision, intelligent detection of electronic control system to protect against hook slipping,
jacking leveling control, jacking motor control to prevent jacking accidents. It is the first time in China tower crane field to
load one-key super-lift function; new slewing reduction and amplitude reduction technology. Adopting quick-loading technology, the
fastest time from unloading to the completion of installation and commissioning is 3h. The industry's first ETI2.0 safety and
intelligent control system, which improves performance, safety and intelligence. Award Level: Won the China Construction Machinery
2021 Annual Product TOP50 A
has a rich combination of boom lengths, with a maximum lifting arm length of 60m, a variable arm length of 5m, a minimum arm
length of 30m, and seven combinations of arm lengths. 4 major institutions have been fully accelerated to improve the overall
efficiency by 35%. Adopting patented jacking safety technology, triple protection of jacking height against topping, double
protection of amplitude against collision, intelligent detection of electronic control system to protect against hook slipping,
jacking leveling control, jacking motor control to prevent jacking accidents. It is the first time in China tower crane field to
load one-key super-lift function; new slewing reduction and amplitude reduction technology. Adopting quick-loading technology, the
fastest time from unloading to the completion of installation and commissioning is 3h. The industry's first ETI2.0 safety and
intelligent control system, which improves performance, safety and intelligence. Award Level: Won the China Construction Machinery
2021 Annual Product TOP50 A
PRODUCT SPECIFICATIONS
|
NO
|
Item
|
T6013-6 SParameters
|
|
1
|
Product Model
|
T6013-6S
|
|
2
|
Product Type
|
tower crane
|
|
3
|
Jib Length/End of Jib Lifting Weight
|
60/1.3 m/t
|
|
4
|
Rated lifting moment
|
110.4t.m
|
|
5
|
Maximum lifting capacity
|
6t
|
|
6
|
Fixed height
|
60m
|
|
7
|
Attachment height
|
220m
|
|
8
|
Lifting capacity rope
|
440m
|
|
9
|
Maximum lifting capacity/amplitude t/m
|
6/ 18.4
|
|
10
|
Max. lifting speed m/min
|
100
|
|
11
|
Luffing speed m/min
|
0-75
|
|
12
|
Rotary speed r/min
|
0~0.8
|
|
9
|
core component
|
PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear,
|
