Soft Cushion Belt Conveyor
Description
产品描述
This is one kind of port crane, like Full Air Cushion Belt Conveyor,Heavy Tank Type Cushion Belt Conveyor, Soft Cushion Belt Conveyor
As a kind of new-type heavy-tank-type belt conveyor which can realize the large transport capacity, the air cushion belt conveyor can apply air cushion to replace the supporting roller bearing and change the rolling friction of supporting roller belt conveyor into fluid friction, as a result, it has reduced the tractive forces of driving device and the operation resistance of belt conveyor. Meanwhile, when there are the same transport capacity and conveying process, the power consumption is saved for 15-30% than the supporting roller belt conveyor.
Structure Principle:
1. Sweeper 2. Transmission roller 3.Trough roller 4. Draught fan 5. Materials groove 6. Redirection roller 7. screw take-up device 8. Hood 9. Rotary controller 10. Headstock 11. Tape 12. Observation hole door 13. Enclosed fitting 14. Gas tank joint 15. Lower parallel roller 16. Pull switch 17. Tension protection 18. Non-loaded cleanser 19. Tail
Basic Structure Type:
1. Full air cushion opening type
2. Full air cushion sealing type
3. Blending opening type
4. Blending sealing type
Cushion belt conveyor is a type of conveyor system that uses a cushioned belt to transport materials from one place to another. The cushioning is typically made of a soft, rubber-like material that helps to absorb shock and reduce the impact of the materials as they move along the conveyor. This type of conveyor is commonly used in applications where delicate or fragile materials need to be transported, such as in the food or pharmaceutical industries. The cushion belt also helps to reduce noise and vibration, making it a popular choice in environments where noise levels need to be kept to a minimum.
