Tractor pole piling machine/augur drill
Description
产品描述
拖拉机杆打桩机/螺旋钻
The earth digger screw pile driver is use tractor or excavator as the power source, match the hydraulic system to realize the mechanical equipment for excavation of the pit. The screw pile driver is generally composed of a power system (tractor or excavator), a hydraulic system, and a mechanical drilling system.
This Tractor pole piling machine compact solution can be quite useful for Pole erection as it helps in reduction of labour and increases the number of poles erected per day thereby significantly reducing the project time drastically. Tractor pole piling machine More safeties are provided in thisearth digger screw pile driver compare to other local earth digger screw pile driver.pile driver/Auger drill
Theearth digger screw pile driver is suitable for all kinds of terrain, such as the loess layer, clay layer, containing pebbles gravel soil, weathered rock and soil, frozen soil, building garbage, backfill sand, garbage layer.pile driver/Auger drill
| 型 | LH-850 | LH-1004 | LH-1004H |
| Driver type | 4*2 | 4*4 | 4*4 |
| Power | 85HP | 100HP | 110HP |
| Steering system | Hydraulic system | Hydraulic system | Hydraulic system |
| Bit material | Alloy steel | Alloy steel | Alloy steel |
| Drill pipe reamer material | Manganese steel | Manganese steel | Manganese steel |
| Hole diameter(mm) | 100-2000 | 100-2000 | 100-2000 |
| Hole depth(mm) | 1000-6000 | 1000-6000 | 1000-6000 |
| Overall size(L*W*H) mm | 5520*2100*2884 | 6520*2170*2894 | 7520*2170*2994 |
| Weight (T) | 6.5 | 6.8 | 7.1 |
| Hoisting machine | 3T,5T,8T | 5T,8T,10T | 8T,10T,12T |
| Dig a pit speed (/sec) | 25-60 | 25-60 | 20-60 |
| Practical geology | Sand and soil including cobble stone ,weathered rock and soil layer ,tundra and backfill garbage | ||
