Osda Dual-Glass N-Type Mono PV Module
Contact Now
Description
Dual-Glass Construction：Features 2.0mm high-transmittance tempered front glass and 2.0mm tempered back glass, with IP68 protection rating, capable of withstanding 5400Pa snow load and 2400Pa wind load 2.
High Efficiency Range：Rated peak power covers 630W to 720W, with a maximum module efficiency of 24.06% under STC conditions 3.
1500V System Compatibility：Maximum system voltage of 1500V, with junction box supporting 1500V DC, suitable for high-voltage photovoltaic systems 24.
This product is the Osda N PRO series dual-glass photovoltaic module launched by Ningbo Osda Optoelectronics Co., Ltd., featuring 132 pieces of 182*105 N-type monocrystalline cells arranged in a 12*11 configuration . Under STC (irradiance 1000W/㎡, cell temperature 25℃, atmospheric pressure AM1.5), its rated peak power ranges from 630W to 720W, with electrical parameters such as maximum power voltage and current varying by model . In terms of mechanical performance, the module measures 2382*1134*30mm and weighs 32.40kg, with a black anodized aluminum frame and an IP68-rated junction box containing 3 diodes. It meets Class Ⅱ safety protection level and Class C IEC fire rating . For operating parameters, it has an operating temperature range of -40~+85℃ and a maximum series fuse rating of 28A. Compliant with multiple international standards including IEC61215:2021 and ISO9001:2015, it provides reliable support for photovoltaic system applications .
