Commercial Cooking Counter With ESP Purifier, Mobile Cooking Counter with ESP purifier,Mobile Fume purification integrated Stove,All-in-one Cooking Counter with ESP purifier, suitable for Restaurants, Barbecue, or mobile street food shops.

Item NO.	KHPH-18	KHMH-181	KHMH-182
Product name	Platform without stove	Single-fire stove	double-fire stove
Power supply	220VAC 50/60HZ, 1.5KW (motor power 1.1kW, Fan full pressure 550PA)
Adsorption area	32sqm
Product size (mm)	1800x830x1770(other size can be order),NW250kgs
Operating platform size(mm)	1800x750x530
Electric field size (mm)	380×600×480X2PCS
volume (m3/h)	4100(7000CFM)
Air speed (m/s)	4.5	4.5	4.5
Purifier rate	97%	97%	97%
Resistance (Pa)	≤180	≤180	≤180
Operating temperature (℃)	<70	<70	<70
Electric field materia	ESP*2pcs (Stainless steel ionizer + tungsten wire electrode, aviation aluminum dust collection unit, spacing 7mm)
Filter	pre-filter 1pcs, ctivated carbon filter1pcs**(Optional)*
Security configuration	Open the door and power off, radiator
Parts have	Water inlet and drain interface, oil collecting tank, LED light switch, fan switch	Natural gas, water inlet and drainage interface, oil collection tank, LED light switch, fan, ignition, firepower adjustment switch

Principle of Purification

1.) First, the cooking oil smoke will rise and meet the metal net plate (stainless steel, detachable, double-layer dislocation design, fire prevention) and condense, resulting in the "Kangda effect" (that means the gas contacts the metal surface and condenses and forms a fluid to achieve oily water, Separation effect), we design a small pull-out "oil tank" at the bottom right corner of the metal net plate, which can be cleaned every day.

2.) After the first filtration, the escaping small particles will enter our electrostatic module through the smoking area after purification (ESP dual electric field glow discharge + electrostatic machine integration, generating positive and negative plasma, double door design, removable cleaning), and the fresh air will coming out through the exhaust outlet gate at back of the machine (the rear exhaust outlet, the built-in fan has an air volume of 4000, reaching a purification efficiency of 97%), and there is no smoke by visual inspection.
