China Top Brand Lifting Machinery: XGT15000-600S Tower Crane for Sale at Discounted Prices

Contact Now

Description

产品描述

Contact

Cecilia Hu
Email: ceciliaATsuperegn.com
Wechat/ Mobile/ WhatsApp: +86 18857378559

Parameter

Work performance	Max. rated lifting capacity kg	13000
	Max. load moment of basic boom kN.m	5115
	Max. load moment of main boom (fully extended) kN.m	2606
	Max. lifting height of basic boom m	14.0
	Max. lifting height of main boom m	64.5
	Max. lifting height of jib m	82.5 / (89.2)
Work speeds	Max. hoist rope speed (Main winch) m/min.	135
	Max. hoist rope speed (Auxiliary winch) m/min.	110
	Boom derricking up time s	65
	Boom extending time s	560
	Max. slewing speed r/min.	0~1.5
Driving	Max. height above sea level m	2000
	Max. driving speed km/h	75
	Max. gradeability %	40
	Min. turning diameter m	≤23
	Min. ground clearance mm	329
	Limits for exhaust pollutants and smoke	Conform to related standards
	Fuel consumption per hundred kilometers L	70
Mass	Deadweight in driving condition kg	54900
	Complete vehicle kerb mass kg	54705
	Load on axles 1 and 2 kg	9950/9950
	Load on axles 4 and 5 kg	25250(dual-axle)/9750
Dimensions	Overall dimensions (L × W × H) mm	15600×3000×3990
	Outrigger spread (L) m	8.25
	Outrigger spread (W) m	7.8 (fully extended), 5.3 (intermediately extended)
	Main boom length m	16.5~64.0
	Boom angle °	-0.5~82
	Jib length m	10.4 ,17.5
	Jib + extension length m	24.5
	Offset °	0 ,15, 30
