Product ID: 68564228
DIN3093 Oval Aluminum Ferrules for Wire Rope Cable
Contact Now
Description
Basic Info.
- Model NO. DIN3093
- Shape Round
- Usage Industrial
- Condition New
- Color Silver
- Purpose Pressing The Wire Rope
- Delivery Time 15 Days
- Sample Available
- Transport Package in Wooden Carton
- Trademark geyo
- Origin China
- HS Code 761699900
- Production Capacity 10000PCS/Month
Packaging & Delivery
- Package Size 15.00cm * 10.00cm * 15.00cm
- Package Gross Weight 15.000kg
Product Description
- 1) A leading manufacturer of aluminium sleeves in China.
- 2) High quality products with competitive price.
- 3) Exporting 50 containers per months abroad from 1994 to now and have won a high reputation in the market.
- 4) An ISO 9001: 2008 Certified Manufacturer.
Part No.
| PART NO. | FERRULE CODE | A (mm) | B (mm) | S (mm) | L (mm) | WEIGHT Kgs/1000Pcs | L(mm) GB 6946-93 |
|---|---|---|---|---|---|---|---|
| GY990010 | 1 | 1.2 | 2.4 | 0.65 | 5 | 0.098 | - |
| GY990015 | 1.5 | 1.7 | 3.4 | 0.75 | 6 | 0.176 | - |
| GY990020 | 2 | 2.2 | 4.4 | 0.85 | 7 | 0.285 | - |
| GY990025 | 2.5 | 2.7 | 5.4 | 1.05 | 9 | 0.439 | - |
| GY990030 | 3 | 3.3 | 6.6 | 1.25 | 11 | 0.907 | - |
| GY990035 | 3.5 | 3.8 | 7.6 | 1.5 | 13 | 1.18 | - |
| GY990040 | 4 | 4.4 | 8.8 | 1.7 | 14 | 1.63 | - |
| GY990045 | 4.5 | 4.9 | 9.8 | 1.9 | 16 | 2.39 | - |
| GY990050 | 5 | 5.5 | 11.0 | 2.1 | 18 | 3.62 | - |
| GY990060 | 6 | 6.6 | 13.2 | 2.5 | 21 | 5.87 | 25 |
| GY990065 | 6.5 | 7.2 | 14.4 | 2.7 | 23 | 7.18 | - |
| GY990070 | 7 | 7.8 | 15.6 | 2.9 | 25 | 9.83 | 30 |
| GY990080 | 8 | 8.8 | 17.6 | 3.3 | 28 | 12.96 | 34 |
| GY990090 | 9 | 9.9 | 19.8 | 3.7 | 32 | 18.94 | 38 |
| GY990100 | 10 | 10.9 | 21.8 | 4.1 | 35 | 24.09 | 42 |
| GY990110 | 11 | 12.1 | 24.2 | 4.5 | 39 | 35.35 | 47 |
| GY990120 | 12 | 13.2 | 26.4 | 4.9 | 42 | 44.18 | 50 |
| GY990130 | 13 | 14.2 | 28.4 | 5.4 | 46 | 59.86 | 55 |
| GY990140 | 14 | 15.3 | 30.6 | 5.8 | 49 | 73.5 | 59 |
| GY990160 | 16 | 17.5 | 35.0 | 6.7 | 56 | 111 | 67 |
| GY990180 | 18 | 19.6 | 39.2 | 7.6 | 63 | 156 | 76 |
| GY990200 | 20 | 21.7 | 43.4 | 8.4 | 70 | 217 | 84 |
| GY990220 | 22 | 24.3 | 48.6 | 9.2 | 77 | 292 | 92 |
| GY990240 | 24 | 26.4 | 52.8 | 10.0 | 84 | 376 | 101 |
| GY990260 | 26 | 28.5 | 57 | 10.9 | 91 | 481 | 109 |
| GY990280 | 28 | 31.0 | 62.0 | 11.7 | 98 | 603 | 118 |
| ...... | |||||||
| ...... | |||||||
| GY990600 | 60 | 66.0 | 132.0 | 25.0 | 210 | 5880 | 248 |
