Energy-Saving Air Source Pool Heat Pump
Contact Now
Description
- Overview
- About Us
- Certificates
- Packaging & Shipping
- Our Service
Basic Info.
Work Environment
Common Heat Pump
Heat Source
Air-source
Application
Villa Family, Sauna and Swimming Pool, Hotels, Factory Hospital, Student Apartments, Beauty Salons
Certification
ISO9001, CCC
Item Name
Air Source Heat Pump
Customized Design
Available
Engineering Technical Support
Available
Cop
3~4
Compressor
Scroll
Transport Package
Safety Standard Export Packaging
Specification
Customized according to clients' engineering needs
Trademark
YIJIAREN or Customized
Origin
Jiangsu, China
HS Code
8419190000
Production Capacity
50000 Sets/Year
Packaging & Delivery
Package Size
205.00cm * 103.00cm * 216.00cm
Package Gross Weight
750.000kg
Product Description
Scroll Type Air Cooled Heat Pump Unit
The scroll-type air-cooled heat pump unit adopts a high-efficiency fully enclosed scroll compressor, a high-efficiency shell-and-tube heat exchanger, and a coil heat exchanger, using R22, R134a, or R407c refrigerants. The energy efficiency rating can reach Level 2, with hot water outlet temperatures up to 75°C. The cooling capacity ranges from 25kW to 118.8kW, and the heating capacity ranges from 25kW to 127.2kW. It is widely used in various small and medium-sized commercial and industrial sites that require hot water for industrial production.
FEATURE
1. The scroll-type air-cooled heat pump unit uses a world-renowned fully enclosed scroll compressor, ensuring stable operation, low noise, and durability. 2. It employs independently developed high-efficiency evaporators and finned condensers, achieving a whole machine energy efficiency rating of Level 2. 3. The inner-threaded shell-and-tube evaporator offers highly efficient heat transfer.
1. The scroll-type air-cooled heat pump unit uses a world-renowned fully enclosed scroll compressor, ensuring stable operation, low noise, and durability. 2. It employs independently developed high-efficiency evaporators and finned condensers, achieving a whole machine energy efficiency rating of Level 2. 3. The inner-threaded shell-and-tube evaporator offers highly efficient heat transfer.
4. The flow device uses a well-known brand thermal expansion valve.
5. The scroll-type air-cooled heat pump unit can be controlled via microcomputer or PLC control, with optional network capabilities for remote monitoring and after-sales service. 6. It uses an external rotor for smooth operation, low noise, and high efficiency.
NORMAL TEMPERATURE AIR SOURCE HEAT PUMP | |||||
TYPE | YJR-HP-10p | YJR-HP-12p | YJR-HP-15p | YJR-HP-20p | |
Heating Capacity | KW | 36 | 48 | 60 | 80 |
Circulating Water Quality | M3/H | 6.2 | 8.23 | 10.32 | 13.71 |
Water Yield | L/H | 773 | 1030 | 1289 | 1715 |
Power Supply | 3N/400V/50Hz | ||||
Rated Power | KW | 9.12 | 10.65 | 13.64 | 18.2 |
COP | 3.94 | 4.5 | 4.39 | 4.39 | |
Rated Current | A | 15.1 | 17.2 | 25.7 | 31.6 |
Max Power | KW | 11.5 | 14.2 | 19.7 | 24.2 |
Max Current | A | 18.9 | 24.8 | 33.5 | 39.8 |
Water Side Pressure Loss | kPa | 65 | 65 | 65 | 75 |
Working System | Compressor Type | Scroll compressor | |||
QTY | 2 | 2 | 2 | 4 | |
Water side heat exchanger | TYPE | High efficiency tank heat exchanger | |||
Refrigerating Fluid | TYPE | R410A | |||
Recharge Qty(kg) | 2.5kg*2 | 3.2kg*2 | 4kg*2 | 3kg*4 | |
Water temperature setting | 40-60 degree | ||||
Applicable ambient temperature | 0 - 43 degree | ||||
Size(mm) | 1410*900*1100 | 985*965*2100 | 1960*965*2100 | ||
Diameter of inlet and outlet | 1.5" | 1.5" | 1.5" | 2" | |
Total weight(Kg) | 320 | 380 | 480 | 750 | |
Noise dB(A) | <60 | ≤60 | ≤62 | ≤65 | |
Product Configuration
1.High-Efficiency Low-Temperature Heat Pump Compressor
The unit is equipped with the mature and reliable ZW series scroll ultra-low-temperature compressor from Copeland (USA), renowned for its advanced production standards. It operates stably within an ambient temperature range of -25°C to 46°C. Through optimized system design and the application of high-quality components, the second-generation Yijiaren air-source heat pump water heater significantly improves performance, especially in heating capacity and service life.
The unit is equipped with the mature and reliable ZW series scroll ultra-low-temperature compressor from Copeland (USA), renowned for its advanced production standards. It operates stably within an ambient temperature range of -25°C to 46°C. Through optimized system design and the application of high-quality components, the second-generation Yijiaren air-source heat pump water heater significantly improves performance, especially in heating capacity and service life.
2.Multi-Circuit Evaporator
The evaporator features a hydrophilic aluminum fin multi-circuit design with internal threaded copper tubes. The blue hydrophilic-coated aluminum fins and threaded copper tubes enhance surface hydrophilicity, facilitating rapid drainage of condensate to minimize frost buildup and ensure thorough defrosting. To enhance durability, the evaporator's heat exchange area is enlarged, enabling uniform and efficient heat absorption from low-temperature heat sources.
The evaporator features a hydrophilic aluminum fin multi-circuit design with internal threaded copper tubes. The blue hydrophilic-coated aluminum fins and threaded copper tubes enhance surface hydrophilicity, facilitating rapid drainage of condensate to minimize frost buildup and ensure thorough defrosting. To enhance durability, the evaporator's heat exchange area is enlarged, enabling uniform and efficient heat absorption from low-temperature heat sources.
3.Copper Tube Heat Exchanger
Utilizing WDD intelligent heating technology, the coaxial spiral copper tube heat exchanger employs turbulent flow heat exchange to prevent scale formation. The seamless copper tube design eliminates internal welding points and water blind zones, while the extended coil length increases refrigerant contact area for higher energy performance.
Utilizing WDD intelligent heating technology, the coaxial spiral copper tube heat exchanger employs turbulent flow heat exchange to prevent scale formation. The seamless copper tube design eliminates internal welding points and water blind zones, while the extended coil length increases refrigerant contact area for higher energy performance.
4.Throttling Device
The system incorporates high-quality domestic brands like Sanhua electronic expansion valves and four-way reversing valves, ensuring automatic adjustment, smooth reversing, no gas leakage, and no jamming. The intelligent control system guarantees stable operation, energy savings, maintaining reliable performance even in extreme cold.
The system incorporates high-quality domestic brands like Sanhua electronic expansion valves and four-way reversing valves, ensuring automatic adjustment, smooth reversing, no gas leakage, and no jamming. The intelligent control system guarantees stable operation, energy savings, maintaining reliable performance even in extreme cold.
5.Low-Noise Fan
Low-speed, high-torque 3D turbo fan auto-adjusts speed for quiet, efficient operation with minimal frost and noise.
Low-speed, high-torque 3D turbo fan auto-adjusts speed for quiet, efficient operation with minimal frost and noise.
6.Intelligent Control System
The air-source heat pump is equipped with a smart controller featuring rational logic and premium materials. It offers comprehensive protection functions, including exhaust protection, overcurrent protection, phase sequence protection, high outlet water temperature protection, and high/low pressure protection, ensuring fully automated and safe operation.
The air-source heat pump is equipped with a smart controller featuring rational logic and premium materials. It offers comprehensive protection functions, including exhaust protection, overcurrent protection, phase sequence protection, high outlet water temperature protection, and high/low pressure protection, ensuring fully automated and safe operation.
Product Superiority
The EVI low-temperature heat pump unit adopts enhanced vapor injection technology, a key R&D achievement of Jiangsu Obuy New Energy Development Co., Ltd. Compared to conventional units, this product demonstrates higher energy efficiency in low-temperature environments, achieving a COP of 2.0 even at an ambient temperature of -25°C, making it an ideal solution for cold northern regions.
Air-Source Hot Water Generation: Utilizes air as the heat exchange medium to produce hot water.
Exceptional Low-Temperature Performance: Equipped with enhanced vapor injection technology, enabling reliable operation at temperatures as low as -25°C without auxiliary electric heating.
High Heating Efficiency in Extreme Cold: Maintains a heating COP of 2.052 at -25°C ambient temperature.
Overcomes Traditional Limitations: Resolves the issues of poor reliability and low efficiency in conventional air-source heat pumps under extreme cold conditions. Particularly suitable for the Yellow River Basin, North China (including Beijing), and Northwest China, significantly expanding the application range of air-cooled heat pumps.
Compact & Space-Saving Design: Features a highly integrated structure with minimal footprint, eliminating the need for a dedicated refrigeration room or cooling tower—reducing space requirements while optimizing investment costs.
Exceptional Low-Temperature Performance: Equipped with enhanced vapor injection technology, enabling reliable operation at temperatures as low as -25°C without auxiliary electric heating.
High Heating Efficiency in Extreme Cold: Maintains a heating COP of 2.052 at -25°C ambient temperature.
Overcomes Traditional Limitations: Resolves the issues of poor reliability and low efficiency in conventional air-source heat pumps under extreme cold conditions. Particularly suitable for the Yellow River Basin, North China (including Beijing), and Northwest China, significantly expanding the application range of air-cooled heat pumps.
Compact & Space-Saving Design: Features a highly integrated structure with minimal footprint, eliminating the need for a dedicated refrigeration room or cooling tower—reducing space requirements while optimizing investment costs.
