Basic Info

• Model NO. P1.86
• Pixel Pitch 1.86mm
• Pixel Configuration 1R,1G,1B
• Pixel Density 160000 Dots/Sqm
• Scanning Mode 1/43
• System Operating Platform WIN XP
• Display Type LED Video Display
• Application Stage Performance, Advertising, Shopping Guide
• IP Rating IP43
• Certification CE
• Pixel Pitch (mm) 1.86
• Module Resolution (W×h) 172*86
• Module Power Consumption Below 30W
• Contrast Ratio 5000:1
• Refresh Rate (Hz) 3840
• Gray Level 16384
• Transport Package Carton, Wooden Carton, Flight Case
• Specification 320x160mm
• Trademark FITECH
• Origin China
• HS Code 8528591090
• Production Capacity 1000 Sqm/Month

Product Description

LED Display

Our LED indoor small pitch module supports advanced HDR digital image technology, with high brightness, high contrast and ultra-wide Angle of view, can obtain high-quality display effect in all angles, high reliability, long service life.

Product Features:

• The display screen is delicate and real, the brightness is stable and uniform, no flicker, no grain sense.
• Nanoscale response, no ghosting trailing phenomenon.
• Uniform ink color, good consistency.
• 3840Hz ultra-high refresh frequency, the screen display is delicate and smooth.
• Broadcast-level grayscale processing display, image details are more abundant.
• Ultra-wide viewing Angle, the viewing Angle can reach more than 140°.
• It can be stitched in any direction and size, and the picture is uniform without stitching.

Product Specifications:

• Module Composition Pixel Composition: 1R1G1B
• LED Packaging SMD1515
• Pixel Pitch (mm) 1.86
• Module Resolution (W×H) 172×86
• Module Size (W×H) (mm) 320×160
• Module Power Consumption ≤30W
• Module Input Voltage 4.5V~ 5V
• Optical Parameters
• Single Point Brightness Correction Function Support
• Single Point Chroma Correction Function Support
• Brightness (cd/m2) 500
• Color Temperature (K) 6500 (adjustable from 2000K to 9300K)
• Visual Angle Horizontal 140°/ vertical 140°
• Light Point Center Distance Deviation < 3%
• Brightness/Chroma Uniformity ≥97%
• Contrast Ratio 5000:1
• Electrical Parameters
• Peak Power Consumption (W/m2) ≤600
• Average Power Consumption (W/m2) ≤195
• Power Supply Requirements AC186 to 264V, frequency 47 to 63 (Hz)
• Handling Performance
• Driving Method Constant current drive 1/40 sweep
• Frame Changing Frequency 50/60Hz
• Refresh Rate (Hz) 1920/3840
• Gray Level 16384
• Processing Depth (bits) 14
• Brightness Control Manual/automatic/programmed
• Usage Parameters
• Lifespan Typical Value (h) ≥50000
• Interface Type HUB75E port
• Operating Temperature/Humidity Range -20°C -- 40°C / 10%-65%RH(no-condensing)
• Storage Temperature/Humidity Range -20°C -- 40°C / 10%-65%RH(no-condensing)

Product Dimensions:

Note: Please note that the parameters above are typical values. Variations may occur between different production batches, and actual product parameters should be verified by the factory inspection report. Our product is subject to continuous optimization and updates during production. For the most accurate details, always refer to the adjusted product specification sheet and consult with regional distributors before purchasing. For any custom orders, a new specification sheet will be provided to ensure tailored accuracy.

Signal Interface Definition:

Equipped with the HUB75E interface, providing reliable connectivity.
