Indoor Full Color HD COB P1.25 LED Display Screen for Home Theatre
Description
Basic Info.
- Model NO. COB-P1.25
- Pixel Pitch 1.25mm
- Pixel Configuration 1R,1G,1B
- Pixel Density 640000/Square Meter
- Scanning Mode 1/48scan
- Display Type LED Video Display
- Application Advertising, Shopping Guide
- IP Rating IP54
- Certification CE, RoHS, CCC, ETL
- LED Type COB
- Module Size 150X168.75mm
- Screen Size 600X337.5mm/675mm
- Screen Resolution 640000dots/Sqm
- Scan Mode 1/48scan
- Brightness 600CD/Sqm
- Refresh Rate 3840Hz
- IP Grade IP54
- Certificate CE RoHS FCC CCC ISO9001
- Cabinet Material Die-Casting Aluminum
- Weight 6.5kg
- Function Display Video
- Module Resolution 120dots X 135dots
- Operation Humidity 10 - 85%
- Warranty 2 Years
- Transport Package Wooden Case
- Specification 600mm x 337.5mm/675mm
- Trademark CKGLED
- Origin China
- HS Code 8528591090
- Production Capacity 6000sqm/Per Month
Product Description
PRODUCT FEATURES:
- The COB led panel cabinet size is 600 x 337.5mm
- Led panel display super slim small pitch design
- The COB led screen supports direct wall mounting and structure mounting.
- Led screen display front maintenance design, easy to installation.
TECHNICAL DATASHEET:
| NO. | ITEM | PARAMETER | UNIT |
|---|---|---|---|
| 1 | Model | COB-1.25 | |
| 2 | Pixel Pitch | 1.25 | mm |
| 3 | Physical Density | 640000 | dots/sqm |
| 4 | LED Configuration: | 1R1G1B | / |
| 5 | LED Type: | COB | / |
| 6 | Module Size | 150x168.75 | mm |
| 7 | Module Resolution | 120x135 | dots |
| 8 | Drive Mode: | 1/48 Constant Current Drive | / |
| 9 | Horizontal Viewing Angle | 140 | Deg |
| 10 | Vertical Viewing Angle | 140 | Deg |
| 11 | Brightness | 600 | cd//sqm |
| 12 | Grey Scale: | 14 | bits |
| 13 | Refresh Rate | ≥3840 | Hz |
| 14 | Color | >4 | T |
| 15 | Input Voltage | AC 110V~220V+/-10% | V |
| 16 | Refresh Frame Frequency | 60 | Hz |
| 17 | Protection Level: | IP54 | / |
| 18 | Maintenance | Front service | / |
| 19 | Working Environment: | Indoor | / |
| 20 | Working Temperature | -30- +60 | ºC |
| 21 | Operation humidity | 10%-85% | RH |
| 22 | Certificates: | CCC, CE, RoHS | / |
PRODUCT DETAILS:
Our Corporate:
Shenzhen Chuangkaiguang Co., LTD (known as CKGLED), a professional LED display factory who specializes in R&D / DESIGN / PRODUCTION / SALES, was established in 2012 with a registered capital of more than $ 12 Million. CKGLED product ranks are indoor/outdoor rental led displays, Ultra small pixel pitch led displays, indoor/outdoor fixed installation led displays, sports / stadium led displays, traffic led displays etc. The company has developed a long-term development strategy plan, adhere to the "Thanksgiving, integrity, innovation, focus" business management philosophy, to create the world's largest LED photoelectric display products integrated manufacturing service provider for the goal, we work together for common developmen.
Our Service
- Your inquiry related to our products or price will be replied within 24hrs;
- OEM&ODM, any customized ideas we are able to help you to design and turn into product;
- Distributor-ship are offered for your unique design and some our current models;
- Protection of your sales area, ideas of design and all your private information;
- Top quality+Reasonable price+ Perfect After Service;
- CKGLED can offer you all kind of led displays for outdoor/ indoor fixed installations, outdoor/ indoor rental screens / ultra small pixel pitch led displays / Perimeter led displays for sports, traffic led displays etc.
- 2years warranty.
Trade Terms
- Package: Anti-shaking wooden package, Air flight case or Carton package;
- Payment: 30% advance payment by T/T, remaining 70% balance after production completed and before shipment;
- Shipping freight are quoted under your requests;
- Shipping port: Shenzhen, China;
- Warranty time: 2 years.
- Delivery time: 5-15 working days.
