UHMWPE Marine Fender Pad for Dock Anti-Sliding Protection
Description
Overview
Basic Info.
Model NO. UHMPE/HDPE
Material UHMWPE
Shape Coner Pad; Edge Pad; Flat Pad
Size as Your Request
Color Customized
Thicknes 6-30mm
Density 0.93-0.97g/Cm³
Logo Customzed Logo Acceptable
Transport Package by Pallets
Specification as your request
Trademark XinXing
Origin China
HS Code 3920109090
Production Capacity 10000 Piece/Pieces Per Week
Product Description
XINXING UHMWPE1000 ultra high molecular weight polyethylene (UHMW-PE) is the first choice material for facing steel fender panels and other heavy duty applications. They also used in corner pad for marine fender cover/ coner marine fender pads for jetty . It combines very low friction with excellent impact strength and a wear resistance much better than steel. Most popular is XINXING UHWMPE1000-DS which is 'double-sintered' and work-hardened for extra durability. The standard colour is black, but if other colours are needed then UHMWPE 1000-V 'virgin' grade also comes in yellow, white, grey, blue, green and red. UHMW-PE1000 materials are compounded to resist ozone and UV radiation. They do not degrade or rot and are easily recycled at the end of their service life.
Our Advantages
- very high impact strenth
- very low fiction coefficient
- very high abrasion resistance
- UV+Ozone resistant
- Non-conducting (optional)
- 100% recyclable, non-rottening
- Cut to size sheet, all size is available with us
Product Parameters
| Item | Test method | Unit | UHMWPE 1000-V | UHMWPE1000-DS |
|---|---|---|---|---|
| Density | ISO 1183-1 | g/cm3 | 0.93-0.95 | 0.95-0.96 |
| Yield Strength | ASTM D-638 | N/mm2 | 15-22 | 15-22 |
| Breaking Elongation | ISO527 | % | >200 | >100 |
| Impact Strength | ISO179 | Kj/m2 | 130-170 | 90-130 |
| Abrasion | ISO15527 | Steel=100 | 80-110 | 110-130 |
| Shore Hardness | ISO868 | Shore-D | 63-70 | 63-75 |
| Friction Coefficient | (Static state) | Unitless | <0.2 | <0.2 |
| Operating Temperature | - | ºC | -80 to +80 | -80 to +80 |
Application
- Low resistance sliding panels for bridge and protection
- low resistance sliding plates on fender panels
- Corner protection for offshore structures, berths and other marine facilities
Specification
UHMW-PE Flat Fender pad ,UHMW-PE Corner Fender pad ,UHMW-PE Edge Fender pad all are all available (Please contact us for special requirements)
Related Products
Irregular Parts for Machinery | Lining sheet | Temporary Road Mats
UHMWPE sheet | Suction Box Cover | Crane Outrigger Pad
About Our Factory
Xinxing is established 1989 and it has a history of 25 years manufacturing engineering plastics such as UHMWPE and HDPE rods, sheets, parts and components. PP, PVC, PTFE products are also involved. The factory covers an area of 36000 square meters which has 7 big workshops for different products application. Xinxing is the only manufacturer that produces both extruded and pressed plastic products in China and represents the most advanced productive forces and highest quality.
FAQ
- how can we guarantee quality? Always a pre-production sample before mass production; Always final Inspection before shipment;
- what can you buy from us? UHMWPE febder pads; crane outrigger pads; wear-resisting liners; radiation sheilding material; UHMWPE/HDPE parts; HDPE sheets; Light/Heavy duty ground mats; Ice rink products
- why should you buy from us not from other suppliers? We are very confident with our in-house system Also as we produce variety of products used in the same field, the clients can get the variety of product mix under one roof
- what services can we provide? Accepted Delivery Terms: FOB; Accepted Payment Currency: USD; Accepted Payment Type: T/T, L/C; If you have any inquiry and interest about our UHMWPE/HDPE Temporary Ground Event Mats Plastic Construction Road Panel, please contact me freely. We are here for you for 24 hours.
