Overview

Basic Info.

Model NO. Marine Fender Facing Pads
Warranty 1 Year
Material PE
Kind Engineering Plastic Sheet
Water Absorption ＜0.01%
Contraction Percentage 2.0%~5.0%
Tensile Strength 81~130MPa
Certificates ISO CE SGS
Thickness 3mm-300mm
Accessories Bolts or Welding
UV Resistance Yes
Compression Strength 30MPa
Shore Hardness Shore D 65
Transport Package Wooden Pallet
Specification Customized size
Origin China
HS Code 3920109090
Production Capacity 6000tons Per Year

Packaging & Delivery

Package Size 1.00cm * 1.00cm * 1.00cm
Package Gross Weight 1.000kg

Product Description

UHMWPE sliding panel marine fender face/facing pads. Traditional dock fender panels are made of steel plates. Although they are durable, they are easily damaged when the ship is docked. UHMWPE fender pads replace traditional marine fenders. They are durable and more flexible. They can better protect the dock and the ship body. The UHMWPE possess a low coefficient of friction which provides a smooth sliding surface for the vessel to travel along the fender face. Our UHMWPE comes in many colors and thickness project requirements. UHMWPE can also be supplied in stand alone applications not related to rubber fenders, for sliding surfaces that do not require any energy absorption.

Detailed Photos

Advantages & Key Features:

Highest abrasion resistance of any polymer, 6 times more wear resistant than steel
Anti-Weather & Anti-Aging
Self-lubricating, Very low coefficient of friction
Excellent chemical & corrosion resistant
Superior impact resistant, Noise- absorption, Vibration-absorption
Temperature range: -260°C ~ +80°C; Very high resistance to cold, doesn't become fragile even under -180°C
High tensile Strength
Non-Toxic and smell
UV resistance
Flame Retardant; Relatively low in water absorption
Excellent electrical properties
Good performance in resisting environment stress crack, 200 times of ordinary PE
No adhesion
Light weight and easier to handle and fix
Cost efficient; Resulting in low energy consumption
Does not rot, split or crack; 100% recyclable
Great liner material for industrial material handling applications
Easy Reprocessed

Product Parameters

Project Name	Unit	Test Method	Test Result
Density	g/cm³	ASTM D-1505	0.94-0.98
Compressive Strength	Mpa	ASTM D-638	≥42
Water Absorption	%	ASTM D-570
Impact Strength	KJ/m²	ASTM D-256	≥140
Heat distortion temperature	ºC	ASTM D-648	85
Shore Harness	Shore D	ASTM D-2240	>40
Friction coefficient		ASTM D-1894	0.11-0.17
