Basic Info

• Model NO. A2 Pro-29
• Cop 4.3 (A7/W35c)
• Function Supply Hot / Cold Water for DHW and Room Heating / Co
• Control Smartphone APP WiFi Control (Internet)
• Structure Default Monoblock, Optional Split Type
• Heating Mode Auto Changeover Room / Tank Heating
• Cooling Mode Auto Changeover Room Cooling / Tank Heating
• Compressor Hybrid Inverter & EVI Type
• Condenser Stainless Plate Heat Exchanger
• Evaporator Finned Heat Exchanger
• Fan Motor DC
• Refrigerant R410A
• After Sales Service 5 Years
• Private Mode Yes
• Inverter Water Pump Optional
• Transport Package Plywood Box
• Trademark Deakon, OEM
• Origin China
• HS Code 8418612090
• Production Capacity 500000 pieces / Year

Product Description

R32 Hybrid DC Inverter Air Source Heat Pump with ERP a+++ 9kw to 24kw Heating Cooling & DHW WIFI Controller

Deakon A1 Pro air source heat pumps absorb heat from the outside air. This heat can then be used to heat radiators, underfloor heating systems, or warm air convectors and hot water in your home.

Different from a ground source heat pump, an air source heat pump extracts heat from the outside air in the same way that a fridge extracts heat from its inside.

Thanks to combined inverter and EVI technology, it can get heat from the air even when the temperature is as low as -25° C. If add our optional solar panel, the working temperature range can extend down to -35ºC.

Heat pumps have some impact on the environment as they need electricity to run, but the heat they extract from the ground, air, or water is continuously being renewed naturally.

DEAKON MODEL

• K-10GWR/2P
• K-10GWR/3P
• K-10GWR/4P
• K-16CWR/5P
• K-20CWR/6P
• K-22CWR/8P
• K-30CWR/10P
• K-42CWR/15P

OEM MODEL

• A2 PRO-7
• A2 PRO-9
• A2 PRO-12
• A2 PRO-14
• A2 PRO-19
• A2 PRO-22
• A2 PRO-27
• A2 PRO-36

Power supply

• Single phase / 200-240V / 50/60Hz
• Three phase / 380V / 50/60Hz

Compressor type

Twin rotor hybrid inverter evi compressor (Optional Panasonic)

Condenser type

Stainless plate heat exchanger

Evaporator type

Hydrophilic aluminium finned copper pipe heat exchanger

EEV

SAGInoMIYA (Optional Carel)

4-way valve

SAGInoMIYA

Refrigerant type

R410a (Optional R32)

Water connection size

• 1 inch
• 1.2 inch

Metal cabinet

Galvanized steel plate sprayed white (Optional color)

Features

• Simple installation - Water connections only
• 30 - 50% reduction in CO2 emissions
• Low running costs
• Low maintenance
• Low noise - unobtrusive and quiet
• No groundwork i.e. trenches or boreholes
• No gas supply, use or ventilation required
• Comparable installation costs to gas red boilers
• Suitable for both apartments & houses
• Flexible, can be connected to under floor heating, low temperature radiators or fan coils
• Helps achieve 3 stars rating and higher in the code for sustainable homes
• Antifreeze function eliminates need for glycol
• 3 to 5 times more efficient
• Advanced Energy Saving Features - Weather compensation built in as standard - Inverter Technology
• Inverter variable speed compressor
• ECO-friendly
• Plate exchanger
• EEV
• Low noise - unobtrusive and quiet
• Easy to install, no groundwork i.e. trenches or boreholes
• Ideal for off gas grid properties
• Single phase power supply with low starting current
• Flexible, can be connected to under floor heating, radiators or fan coils
• As a package of energy saving measures, helps towards higher rating in the Code for Sustainable Homes
• Can be connected with a solar thermal system which can provide 60% of your hot water needs.

Quality Management System Certification

Pack

FAQ

Q1> What does Juyang New Energy do?

A1: Juayng New Energy is professional manufacturer of various types of heat pump and other HVAC products

Q2> What is the daily production of Juyang New Energy?

A2: Juyang New Energy produce heat pumps around 500~700 PCS / day.

Q3> What is Juyang New Energy certification?

A3 : Juayng New Energy have : SGS, CE, CB, IEC60335-2-40, EN14511 certificate from TUV Lab,, got ISO9001. ISO18001, ISO14001 and CCC certificate. Get Class A+, A as ErP EN14825 test report .

Q4> Where are the products of Juyang New Energy export to till now?

A4 : Currently the products has been exported to Western Europe, North Europe, South Africa, Middle-East, North American.

Q5> What is the marketing cooperation strategy with Juyang New Energy?

A5: Juayng New Energy is finding exclusive agent / distributor / wholesale / OEM

   Juyang New Energy is a manufacturer , so we do not directly face to end user / retail , after signed sales contract for the region , we will do not sale products to others buyers in the area, the agent / distributor is in charge of the sales & service .

Q6> What Juang New Energy can do for their agent / distributor /OEM ?

A6 : Juyang New Energy offer training of sales, installation, maintenance. project design and test.

Q7> How to get training from Juayng New Energy ?

A7 : We welcome customer to visit to Juayng for training or technical exchange ,  or customer can invite our engineer team to their side, Customer also can get online trainning.

Q8> What Juyang New Energy offer to their business partner ?

A8:  Juyang New Energy offer 1%~2% free spare parts according to order quantity .

   Offer whole market exclusive sales right in the specified region

   Offer rebate according to agent sales amount within one year .

   Offer best competitive price & repair parts .

   Offer 24 hours online service .

Q9>  Where is Juayng New Energy's heat pump using ?

A9:  Because Air source heat pump save energy around 70% , ( Inverter heat pump and central cooling & heating heat pump ) is Widely used in home heating, hotels hot water & heating , restaurants, hospitals,schools, bath center, residential central heating and hot water plants, etc.

Welcome visit ours factory, any more question please conatct us.
