Europe New Design R32 Air Source Monobloc Heat Pump Air Conditioning DC Inverter Cooling Heating Hot Water **Title Suggestion:** **R32 Air Source Monobloc Heat Pump with DC Inverter for Cooling, Heating & Hot Water**
Description
Overview
Model NO. VLKS-16CPB2B
Heat Source Type Air Source Heat Pump
Color Black
Warranty 2 Years
APP-Control Yes
OEM Yes
Installation Freestanding
Lead Time 25-35 Days
Water Pump Wilo
Max Outlet Water Tem.(R32) 60ºC
Compressor DC Inverter Twin Rotary Compressor
Type Monobloc
Refrigerant R32
Water Side Heat Exchanger Plate Heat Exchanger
Air Side Heat Exchanger Copper Tube Hydrophilic Aluminum Fin
Housing Material Galvanized Sheet
Function Space Heating, Hot Water, Cooling
Transport Package Carton Box, Plywood Case
Specification 1115mm*1280mm*425mm
Trademark OEM
Origin China
HS Code 8418612090
Production Capacity 30000 Pieces/Year
Product Parameters
| Model | VLKS-06CPB2B | VLKS-09CPB2B | VLKS-12CPB2B | VLKS-16CPB2B |
|---|---|---|---|---|
| Heating capacity A7/W35ºC(EN14511) | 6.21KW | 8.9KW | 12KW | 16.3 |
| Heating capacity A2/W35ºC(EN14511) | 5.56 | 7.97 | 10.8 | 14.49 |
| COP A2/W35(EN14511) | 4.56 | 4.53 | 4.43 | 4.49 |
| COP A7/W35 (EN14511) | 4.93 | 4.92 | 4.8 | 4.88 |
| Cooling capacity A35/W7ºC | 4.9 | 5.9 | 8.1 | 11.4 |
| EER A35/W7 (EN14511) | 2.97 | 2.95 | 2.86 | 2.85 |
| Cooling capacity A35/18 (EN14511) | 6.35 | 8.1 | 11 | 15.6 |
| EER A35/W18 (EN14511) | 3.97 | 3.89 | 3.53 | 3.63 |
| Electric supply | 230V/50Hz | 230V/50Hz | 230V/50Hz | 230V/1Ph Hz |
| Refrigerant | R32 | R32 | R32 | R32 |
| Unit dimensions LXWXH | 1115x425X710 | 1115x425x710 | 1115x425x960 | 1115x425x1280 |
| Package dimension LXWXH | 1160x520x860 | 1160x520x860 | 1160x520x1110 | 1160x520x1440 |
| Net Weight | 90 | 90 | 105 | 140 |
| Noise level | 46 | 46 | 50 | 52 |
| Loading quantity for 20'/40' | 44/88 | 44/88 | 44/88 | 22/44 |
Product Description
Europe New Design R32 Air Source Monobloc Heat Pump Air Conditioning DC Inverter Cooling Heating Hot Water
- ECO friendly new refrigerant: R32
- GWP (Global Warming Potential) only 675, only approximately 1/3 compare with R410A.
- Higher efficient technology:
- 15 years in manufacturing heat pump
- Well-known brand Mitsubishi compressor, twin-rotary and DC Inverter technology, the twin rotors balance each other for anti-vibration, creates lower noise and more efficient.
- Welling Brushless DC fan motor, with good quality of long time running test and low noise.
- Saginomiya brand electronic expansion valve for precise refrigerant control.
- Wilo DC inverter Water pump, Low noise, low vibration, high efficiency, high reliability, easy maintenance
- Brushless DC motor
- High COP/EER performance for save energy
Monobloc Air Source Heat Pumps Working Principle Diagram. Vegardis provides the monobloc heat pump with an integrated main circulation pump. During installation, the installer needs to ensure the proper connection of the heat pump with other components, such as the buffer tank (for space heating/cooling), storage water tank (for domestic hot water), and water pumps (for circulating space heating/cooling water and domestic hot water). Additionally, external fittings are required, including the safety valve, water refill valve, and hot water valves (three-way valve). It is necessary to incorporate a temperature sensor in the storage water tank. Furthermore, an additional electric heater can be installed in either the DHW tank or the buffer tank, allowing it to receive control signals from the heat pump.
FAQ
- 1. How many years have your company been in heat pump industry? Over 15 years in heat pump industry with 200 staff, 20 engineers team
- 2. Do you accept OEM & ODM? Yes. We can produce high quality custom made air source heat pump according to customers' requirement, modify the products to satisfy client's requirements and work together with clients to design a new product.
- 3. What support do you offer to clients? We can provide product certification requirements for local markets; provide catalogs, technical manuals;
- 4. How long is the Heat Pump delivery time? Generally production time will be 25-35 days,
- 5. What is your terms of payment for heat pump ? For small order, 100% paid in advance. For big order 30% T/T in advance, balance before shipment.
- 6. How long can I get feedback after sending inquiry We will check inquiry and message everyday. Our sales clerk will reply to you accordingly in 24 hours. Please complete your email and telephone or mobile number in your personal information so that we can contact you soon.
- 7. How about the quality control? Finished products 100% inspected before package
- 8. How about the shipment? We provide shipment by sea or by train according to your requirements.
- 9. How is your service? We provide pre-sales, in-sales and after sales service within 24 hours
CE Certificate
ERP Label
Lab
