Basic Info.

• Model NO. MGSDC-030IIC
• Work Environment Common Heat Pump
• Heat Source Air-source
• Heating Type Multi-power Heat
• Application Villa Family, Hotels, Factory Hospital, Student Apartments, Beauty Salons
• Certification CE, ISO9001, CCC, CB, RoHS, SASO
• Name DC Inverter Heat Pump with R32 and WiFi
• Function House Heating Cooling and Hot Water
• Voltage 220V-380V/Inverter
• Refrigerant R32
• Working Ambient Temperature -25°C-43°C
• Max Hot Water Temperature 55°C-60°C
• Transport Package Play Wood
• Specification 1270*429*1621
• Trademark mango energy
• Origin China
• HS Code 84189910
• Production Capacity 50000 Unit/Year

Product Description

MANGO EVI DC inverter air source heat pump is the best choice for places where hot water is in demand such as private houses, villas, restaurants, hotels, beauty salons, fitness centers, SPA and massage centers, public baths, hospitals, dormitories, aquaculture farms, etc.

With outstanding features of high efficient and energy-saving, safe and reliable, environmental-friendly and comfortable, low operation costs, etc, it is a direct replacements for traditional hot water devices like coal, oil and gas boilers.

• a. DC inverter EVI compressor and R32 refrigerant for best operation in cold winter.
• b. Low noise fan motor with metal fan blades, durable and reliable.
• c. World famous brands of components, such as Danfos electronic expansion valves, SANHUA 4-way valves, LG AC contactor and etc..
• d. With complete testing for good quality and highest COP.
• e. All copper material for water pipes.
• f. Strong wooden case packing for safe sea transportation.
• g. Advanced control system for reaching all of your requirements.

R32 EVI Full DC inverter Heating & Cooling & DHW Function

General Info

• ErP Level (35°C) A+++
• ErP Level (55°C) A++
• Max. Power Input kW 3.3+3/3.5+3
• Max. Running Current A 15+13.6/5.3x3+13.6
• Compressor Brand Panasonic
• Fan Motor Type DC motor
• Water Side Heat Exchanger SUS 316 Brazed plate heat exchanger
• Air Side Heat Exchanger Finned Heat Exhanger
• Display Micro processor based digital wire controller with LCD display
• Wi-Fi Function Yes
• Rated Water Flow m³/h ≥1.6
• Water Pressure Drop kPa 30
• Water Pipe Connection inch 1"
• Sound Pressure Level at 1m dB(A) 43~54
• Operation Range °C -30~43
• Max. Outlet Water Temp. °C 55~60
• Water Proof Class IPX4
• Electricity Shock Proof I
• Net Weight kg 76
• Net Dimensions (L×W×H) mm 925X375X745
• Package Dimensions (L×W×H) mm 1010X435X890

TERMS AND CONDITIONS

1. The above quotations based on EW-Works prices for samples Order; FOB prices for mass/container Order.
2. Payment: Samples order 100% full paid before production. For mass orders, by T/T, 30% in advance+ 70% before shipment.
3. Lead time: 45 working days around after down payment received.
4. Warranty: 3 years for compressor and heat exchanger, 2 years for other components. Failure caused by improper installation or operation is not applicable for this warranty.
5. 1% free spare parts are offered for full container level (Full Container Order) order.

Details Images

ABOUT US

Mango (European) New Energy Technologu s.r.o. is a joint venture company with GuangZhou Mango Energy Technology Co.Ltd. As one of the professional and leading heat pump manufacturers in Slovakia with advance environmental technology, Mango Energy dedicates to the manufacturing of high quality heat pump products for all fields.

Mango Energy has possessed international advanced whole set equipment of manufacture and test. Our factory has been operating strictly according to the standard of ISO 9001-2000 and ISO 14001:2004. And all of our products have achieved CCC, CE, TUV, and ICE Certificate. All the exporting models are strictly in accordance with the latest EN14511 test standard and EHPA requirement.

More than 70% of Mango Energy products are exported to Europe and other oversea markets. As one of the largest manufacturers of air source heat pumps in the world, Mango Energy occupies the core role in the high-end global market. Mango Energy pays great attention to absorb and integrate the advanced technologies of heat pump in the world and keeps close communication with the overseas Research & Development organizations.

FAQ

Q1> What does mango energy company do ?
A1: Mango energy is professional manufacturer of ON/OFF heat pump, DC inverter heat pump, air source heat pump, water to water heat pump, swimming pool heat pump, high temperature heat pump so on all kind of heat pump.

Q2> What is the daily production of Mango energy company ?
A2: Mango energy one day produce heat pump water heater around 150~255 PCS / day.

Q3> What is Mango heat pump certification ?
A3 : Mango energy have : SGS, CE, CB, IEC60335-2-40, EN14511 certificate from TUV Lab,, got ISO9001. ISO18001, ISO14001 and CCC certificate. Get Class A+, A as ErP EN14825 test report .

Q4> Where are the Mango energy heat pump export to till now ?
A4 : Currently the products has been exported to Western Europe, North Europe, South Africa, Middle-East, South American and Australia market.

Q5> What is the marketing cooperation case with Mango energy ?
A5: Mango energy all find exclusive agent / distributor / wholesale / OEM. Mango energy is manufacturer , so we do not directly face to end user / retail , After sign sales contract at this district , we will do not sales to others buyers again, So agent / distributor care for this district sales & service .

Q6> What Mango energy do for their agent / distributor /OEM ?
A6 : Mango energy offer sales training, heat pump & solar air conditioner product training, After sales service training, maintenance machine training, big air chiller, or heating Project design case training, inside parts exchange training and test training.

Q7> How can get training from Mango energy ?
A7 : If have time , can visit to my factory to training, or invite we engineer team to yours side Training, or by Video training online.

Q8> What Mango energy offer to their business partner ?
A8: Mango energy offer 1%~2% free spare parts according to order quantity .Offer whole this district market exclusive sales right .Offer rebate as this district agent sales amount within one year .Offer best competitive price & repair parts .Offer 24 hours online service .

Q9> where is Mango energy heat pump using ?
A9: Because Air source heat pump save energy around 70% , ( EVI heat pump and central cooling & heating heat pump ) is Widely used in home heating, hotels hot water & heating , restaurants, hospitals, schools, bath center, residential central heating and hot water plants, etc. Any more question you can contact us.
