Overview

Basic Info.

Model	Unit	WSIW-5 WSIA-5	WSIW-10 WSIA-10	WSIW-15 WSIA-15	WSIW-20 WSIA-20	WSIW-25 WSIA-25	WSIW-30 WSIA-30	WSIW-40 WSIA-40
Refrigeration Capacity	kW/h	15	30.5	45	61	69	92	122
	kcal/h	12900	26230	38700	52460	59340	79120	104920
Compr-essor	Type	Scroll Type
Input Power	kW	4.5	4.5*2	4.5*3	9*2	10*2	9*3	10*3
Horses	HP	5	5*2	5*3	10*2	12*2	10*3	12*3
Evapo- rator	Type	Shell and tube Evaporator
Pipe Diameter	Inch	1	2	2-1/2	2-1/2	2-1/2	2-1/2	2-1/2
Refrige-rant	Type	R22
Quantity	kg	2.5	5	7.5	10	11	12	18
Controlled by	Expansion Valve
Water cooled Conden-ser	Type	Shell and tube
Pipe Diameter	Inch	1	1-1/2	1-1/2	2	2-1/2	2-1/2	2-1/2
Water Flow	L/min	40	80	120	160	200	240	300
Air Cooling Conden-ser	Type	Finned Cooler
Blower Power	kW	0.2*2	0.4*2	0.8*2	0.8*2	0.8*2	0.8*3	0.8*3
Water tank	L	50	70	125	140	140	150	180
Pump	Power	0.75	1.5	2.2	4	4	4	4
Max Flow Rate	L/min	57	225	225	420	650	650	650
Max Pressure	kg	1.2	1.9	1.9	2.1	2.1	2.1	2.1
Pipe Diame-ter	Cooling Water Outlet	1/2*4	2	2-1/2	2-1/2	2-1/2	2-1/2	2-1/2
	Cooling Water Inlet	1/2*4	2	2-1/2	2-1/2	2-1/2	2-1/2	2-1/2
Total Air-cooled Power	kW	5.25	10.5	15.7	22	24	31	34
Total Water-cooled Power	kW	5.65	11.3	17.3	23.6	25.6	33.4	36.4
Protection System		Overload, High/low pressure, Anti-freezing, Reverse Phase and Low Temperature Protection
Dimen-sions	Water Cooling	10958100	15570128	20681141	21086144	21084144	26595160	265115160
	Air Cooled	13163115	18391160	196106160	220105165	220105190	255115190	30595195
