Product ID: 68590082
Flexographic Printing and Processing Machine
Contact Now
Description
Basic Info.
| Model NO. | FDC1000 |
|---|---|
| Species | Metal Die |
| Imprinting Type | Platen |
| Placing Form of Template | Vertical |
| Die Cutting Tool | Metal Mold |
| Computerized | Computerized |
| Automatic Grade | Automatic |
| Application | Paper Packaging Materials, Stickers Products |
| Max Cutting Width | 1000 |
| Paper Gram Weight | 150-350GSM |
| Production | 260-380times/Min |
| Air Pressure Requirement | 0.5MPa |
| Air Pressure Consumption | 0.25m |
| Transport Package | Flexo Packaging |
| Specification | 3500*1800*1900 |
| Trademark | FEIDA |
| Origin | China |
| HS Code | 84411000 |
| Production Capacity | 500 Sets/Year |
Product Description
Technical Specification
| Model | FDC-1000*400 |
|---|---|
| Max cutting width | 1000 |
| Cutting precision | ±0.20mm |
| Paper gram weight | 150-350gsm |
| Production capacity | 260-380times/min |
| Air pressure requirement | 0.5Mpa |
| Air pressure consumption | 0.25m³/min |
| Total power | 10kw |
| Weight | 4T |
| Max roller diameter | 1500mm |
| Dimension | 3500x1900x1900mm |
Introduction:
FD series automatic roll punching machine based on international advanced technology, it's widely used in printing, packaging and paper products industries. It adopts micro-computer, human-computer control interface, servo positioning, alternating current frequency converter, manual pneumatic lock plate, photoelectric correcting deviation system, centralized oil lubrication. All the key parts and controls of the machine are imported from international top brand.
FAQ
- Q1. What Kinds Of products Can Be Made On Feida die punching Machine ?
Feida roll die punching machine is suitable for paper cup, paper plate, without any indentation - Q2. What Is The Packing Way Of The Machine for delivery?
Usual, flexible packaging with iron underframe, or you can request for wooden case for extra pay - Q3. What Is The Machine Delivery Time ?
As Generally speaking, 35--40 days shippment after confirming layout. - Q4. How About The Machine Guarantee?
One year. During this period, any parts damaged caused by machineself, the seller will repair/replace the spare parts for free. After one year, the seller will supply the spare parts to buyers as the cost. The machine service is all around the machine life. - Q5. What About The Machine Installation And Training ?
If customer request, we will send our technician to install and train operation. Buyer bears 100USD allowance per day, tickets, accommodation, food - Q6. What Is The Terms Of Payment ?
By 100%T/T , 30% of deposits should be paid in advanced, then 70% of balance should be paid before shippment. Or L/C at sight, both are ok.
