Basic Info.

Model NO.	XNY-001
Persons	11 - 19
Speed	1.00 - 2.00m/s
Control Mode	Collective Selective Control
Position of Computer Room	Without Computer Room
Elevator Door	Center Opening Door
Door Knife	Single
Deceleration Device	With Deceleration Device
Attendant	Without Attendant
Elevator Type	Passenger Elevator
Machine Room Type	with Machine Room
Door Open Way	Center Open, Side Open
Door Open Size	700mm~1300mm
Door Height	2100mm (Standard)
Main Power	AC 380V, 3 Phase 50Hz
Lighting Power	AC 220V, 1 Phase, 50Hz
Production Time	15~30 Days
Warranty	18 Months After Shipment
Product Standard	En 81-20: 2014, En 81-50: 2014
Transport Package	Plywood Box
Specification	EN81, GB7588-2003
Trademark	SYNEY or OEM
Origin	Zhejiang, China
HS Code	8428101090
Production Capacity	11000 Sets Per Year

Product Description

Good Price 1600kg Hospital Elevator for Medical Use Two Handrails

Model: XNY-001

There is a strict requirement for bed elevators because of the special environment in the hospital. Focusing on human-oriented design, Syney precisely controls elevator traveling speed and attentively makes comfortable space for passengers.

Syney bed elevator uses the new data network control technology to achieve intelligent elevator running, maximize lift utilization, and reduce patient waiting time. Meanwhile, using the world's most advanced permanent magnet synchronous motors, elevator realized digitization, low power consumption and long life. Functions designed for medical needs, highlights the people-oriented meticulous care.

Features

Safe and reliable: Syney passenger elevator puts safety first, to ensure each passenger's safe delivery to destination.
Space configurability: From the view of space saving, Syney passenger elevator make new layout of machine room, improved the space availability.
Energy saving and environment friendly: Syney passenger elevator adopts gearless permanent magnet synchronous machine to save energy and protect environment.
High performance: Syney passenger elevator is equipped with stable control system with maximum capacity 1600kg. Intelligent lift dispatching system provides the best solution for customer riding.
People-oriented Cabin Design: The application of efficient center opening door system and deep cabin design, maximized the width when elevator doors open, which makes beds free access to elevator.

Good Price 1600kg Hospital Elevator for Medical Use Two Handrails

Parameters: Hospital Bed Elevator With Machine Room

CAPACITY	SPEED	CABIN SIZE	SHAFT
DL	V	CW	CD	OP	Shaft size	Min.Shaft	Pit Depth(mm)	OH (mm)	MRH(mm)
(kg)	(m/s)	(mm)	(mm)	(mm)	HW (mm)	HD (mm)	HW (mm)	HD (mm)	STD	Min	STD	Min	STD	Min
1350	1	1300	2300	1000*2100	2350	2800	2400	2800	1500	1400	4500	4200
1.5	2450	2800	1600	1550	4600	4400
1.75	2500	2850	1700	1650	4700	4500
1600	1	1400	2400	1100*2100	2500	2900	2400	2800	1500	1400	4500	4200	3000	STD-200
1.5	2450	2800	1600	1550	4600	4400
1.75	2500	2850	1700	1650	4700	4500
1600	1	1400	2400	1200*2100	2300	2900	2300	2950	1500	1400	4500	4200
1.5	2350	3000	1600	1550	4600	4400
1.75	2350	3000	1700	1650	4700	4500

Note: Above standard specification is only for reference. If shaft size at jobsite is different, please contact with us, factory will design suitable one according to your parameter.

Manufacturing, Packing and Delivery

From the raw material getting into factory to finished products getting out to customers, Syney has a strict operation system to control each steps. No rejected raw material will be accepted!

When raw material comes to factory, QC department will check all the materials, once any fault items found, it will be returned to suppliers at once. Only qualified material will get into raw material warehouse.

Production management: Every week, production department will make the production plan and update the schedule of online products. There is digital board in each workshop showing the production plan everyday. In this way, from workers to managers all clearly know which project is online now.

Every morning, managers will guide the workers to run for 15 minutes first to refresh. Then check the machines status before operation and check again after one day job.

Packing: All parts are packed in solid plywood boxes, which can stand long time sea shipping and fumigation free. For some important parts like control cabinet, door operator and motor, parts will be covered by a strong film first, with desiccant, before put into boxes.

Quality control:

All raw materials will be checked before get into warehouse. And bulk electronic product do sampling inspection. All parts must have qualified certificate from suppliers. QC1 is responsible for this.
During production stage, QC2 will check commissioning for each elevator, escalator and moving walks.
After elevator and escalator finished, QC3 will test the match of elevator motor and control cabinet, and the running condition of escalator and moving walks.
After packed, QC4 will check package condition for each parts, and takes photo for further reference.
When delivery, QC5 will check if all parts packed in container to avoid any missing, and takes photo for further reference.

About Syney Electric (Hangzhou) Co., Ltd.

Syney Electric (Hangzhou) Co., Ltd. is a professional enterprise integrating R&D, design, manufacture, marketing, installation and customer service. The company applies whole set of advanced equipment and specializes in design and manufacture of products including passenger elevator, panoramic elevator, bed elevator, cargo elevator, home elevator, car elevator, escalator, moving walks, etc. Syney sales network expands to over 50 countries in Europe, Asia, Africa and America.

The enterprise has two manufacturing factories. The registered capital is ¥500,000,000, covering nearly 99000 square meters, with over 80 engineering technicians and nearly 30 senior managers.

Certificates

CE Certificate of Elevator with machine room and Elevator without machine room, and UCMP device
CE Certificate of energy-efficiency of lifts: Grade A
EAC Certificate Elevator with machine room and Elevator without machine room
