Product ID: 68592540
Chinese Brand New 3Tons Telescopic Handler Price
Contact Now
Description
Basic Info.
| Model NO. | df |
|---|---|
| Type | Diesel Forklift |
| Power | Diesel Engine |
| Load Capacity | 10T - 18T |
| Fuel | Diesel |
| Load center | >500mm |
| Lift height | 3000~5000mm |
| Condition | New |
| Overall Dimensions | 2873*4425*5835mm |
| Spare Parts | Along with Equipment |
| Transport Package | Naked in Container |
| Specification | CE |
| Trademark | Super-above |
| Origin | Jiangsu, China |
| HS Code | 8705109100 |
| Production Capacity | 1000PCS/Year |
Product Description

High quality:
- --Adopt gradeability improving style electronic hydraulic transmission, compare with other models: efficiency 5% improved, climbing torque 8% increased, noise 3~5dB reduced, thermal equilibrium temperature 8-10° decreased;
- --The super large capacity aluminum tube belt radiator and optimized heat dissipation channel further improve the heat dissipation capacity of the vehicle;
- --Load sensing priority steering hydraulic system is adopted to reduce pressure loss of hydraulic system, save energy and improve operation comfort.
High security:
- --Introducing advances technology from Germany, the unique single chain has greatly enhanced he front view while working.
- --All car LED lights, high brightness, long life, energy saving and environmental protection.
High comfort:
- --The new suspension system, adjustable seat, allowing the driver to feel more comfortable and reducing fatigue during long operations;
- --The combined color instrument has strong human-machine interaction and timely and accurately feedback the running state of vehicles.
- --Spacious control space, comfortable seats, enjoy the pleasure of riding.
Rich options:
- high exhaust device, air prefilter, fireproof cap, solid tire, two stage free lift mast, three stage free lift mast , widening fork frame, fork sleeve, side shifter, paper roll clamp, bale clamp, carton clamp, block clamp, rotators, drum clamp, push-pull, etc.

Product Parameters
| Model | SA530 |
|---|---|
| Specifications | Power Unit: Diesel |
| Operator Type | Driver/Seat |
| Transimission Box Type | Automatic Transimission |
| Rated Capacity | 3000 kg |
| Load Center | 500 mm |
| Max. Lifting Height | 3000 mm |
| Tire Type | Pneumatic Tire |
| Tire Number | Front: 2 | Rear: 2 |
| Tire Size | Front: 28×9-15-14PR | Rear: 6.5-10-10PR |
| Lifting Speed (Loaded) | 480 mm/s |
| Lifting Speed (Unloaded) | 500 mm/s |
| Lowering Speed (Loaded) | 420 mm/s |
| Lowering Speed (Unloaded) | 400 mm/s |
| Travelling Speed (Loaded) | 20 km/h |
| Travelling Speed (Unloaded) | 21 km/h |
| Max. Gradeability (Loaded) | 20 % |
| Max. Drawbar Pull (Loaded) | 17 kN |
| Mast Tilting Angle (Fwd/Bwd) | 6/12 deg |
| Free Lifting Height | 150 mm |
| Turning Radius | 2395 mm |
| Overall Length (with fork) | 3800 mm |
| Overall Width | 1240 mm |
| Overhead Guard Height | 2145 mm |
| Fork Size (LxWxT) | 1220×125×45 mm |
| Mast Height (Fork lowered) | 2140 mm |
| Battery (Voltage/Capacity) | 12/90 V/Ah |
| Truck Weight | 4250 kg |
| Fuel Tank Capacity | 70 L |
| Engine | Brand: XINCHAI | Model: C490, C240 |
| Rated Power | 40/2650 kW/rpm, 35.4/2500 kW/rpm |
| Rated Torque | 160/1600-2000 N·m/rpm, 137.7/1800 N·m/rpm |
| Number Of Cylinder | 4 |
| Displacement | 2.67, 2.37 L |
