Jinko Bifacial Solar Panels (450W-600W) with CE & TUV Approval for Sale
Contact Now
Description
Overview
Basic Info.
- Model NO. FSP-550W
- Number of Cells 144PCS
- Application Solar Panel System / Solar Pump / Power Station
- Condition New
- Certification ISO, CE
- Material Monocrystalline Silicon
- Product Name Monocrystalline Solar Panel 500W
- Solar Cell 182*182mm, Anti-Pid
- Frame Color Silver or Black
- Efficiency More Than 21% Efficiency
- Frame Anodized Aluminium Alloy
- OEM Welcome
- EVA >91% Higher Transmittance EVA
- Solar Cells Mono 10bb Half Cut
- Junction Box IP68 Water Proof
- Strength Frame 120n Tensile
- Color of Frame Sliver and Black Color Optional
- Cable 4mm2 Qualified Cable with Mc4
- Solar Cells Sorting Color and Performance Selection
- Middle Test EVA and Appearance Inspection
- Overall Inspection PV Module Appearance
- Transport Package 2PCS/Carton
- Trademark Flagsun
- Origin China, Jiangsu
- HS Code 8541402000
- Production Capacity 100MW/Year
Packaging & Delivery
- Package Size 228.00cm * 114.00cm * 3.50cm
- Package Gross Weight 29.000kg
Product Description
Specification
- Weight 29kg
- Dimensions 2279mm * 1134mm * 35mm (1.5mm Cell Gap)
- Cell Dimensions 182*182mm
- Cell Amount 72*2 pcs
- Maximum System Voltage 1500V
- Junction Box IP68
- Frame Aluminum Alloy
- Cable 4mm2, Landscape: N 1400mm / P 1400mm Portrait: N 200mm / P 300mm
- Connector MC4 compatible
- Application Level Class A
ELECTRICAL PARAMETERS AT STC
- Power 530W / 535W / 540W / 545W / 550W
- Open Circuit Voltage 49.00V / 49.20V / 49.40V / 49.60V / 49.80V
- Short Circuit Current 13.76A / 13.81A / 13.87A / 13.93A / 13.99A
- Maximun Power Voltage 40.80V / 41.00V / 41.20V / 41.40V / 41.60V
- Maximum Power Current 13.00A / 13.05A / 13.11A / 13.17A / 13.23A
- Module Efficienty 20.7% / 20.9% / 21.1% / 21.3% / 21.5%
TEMPERATURE CHARACTERISTICS
- NMOT 41±3ºC
- Temp Coefficient of ISC ±0.05%/ºC
- Temp Coefficient of voc -0.28%/ºC
- Temp Coefficient of Pmax -0.36%/ºC
PACKING CONFIGURATION
- Modules/Pallet 31 Pieces
- Modules/40'Container 620 Pieces
- Packing Description 20 Pallets, Total=(31+31)x10=620 Pieces
MAXIMUM RATING
- Output Tolerance 0~+5W
- Operating Temperature -40ºC~+85ºC
- Wind Load/Snow Load 2400pa/5400pa
- Fuse Current 25A
