Plastic Film Shredder Machine for Tyre, Scrap Metal, Mattress, and Solid Waste
Description
Overview
Basic Info.
| Model NO. | ZT-502 |
| Material | Alloy Steel |
| Usage | Coal, Industrial, Metal, Plastic, Wood, Solid Waste, Animal Carcass, Medical/Solid/Industrial/Household Waste, etc. |
| Crushing Degree | Fine Grinding Machine |
| Principle | Fixed Culling |
| Cutter Material | Hard Alloy |
| Finished Surface | Cut off Tool |
| Compressive Strength (for Crushing) | >300MPa |
| Tongs' Features | Adjustable Tongs |
| After-Sales Service | 24 Hours Service |
| Warranty | 1 year |
| Type | Two Sharft Crusher |
| Object | Medical Waste |
| Crushing Style | Shearing |
| Product Name | Crusher Shredder Machine |
| Model | Zt-600 |
| Crushing Chamber Width(mm) | 600*550 |
| Overall Size(mm) | 3000*2000*1100 |
| Capacity(T/H) | 0.3-5 |
| Power(Kw) | 18.5*2 |
| Blade Diameter(mm) | 260 |
| Body Dimension | Customizable According to The Venue |
| Control | Full PLC Control |
| Packing | in Wooden Case or Carton with Export Standard |
| Core Components | PLC, Gearbox, Motor, Gear, Pump |
| Sharft Design | Double |
| Voltage | 380V |
| Transport Package | with Wooden Box |
| Specification | ZT-600 |
| Trademark | ZTHB |
| Origin | Shandong Province, China |
| HS Code | 8477800000 |
| Production Capacity | 30sets Per Month |
Packaging & Delivery
| Package Size | 3000.00cm * 2000.00cm * 1100.00cm |
| Package Gross Weight | 2850.000kg |
Product Description
Plastic Film Shredder Machine Woven Bag Shredding Crusher for Tyre/Scrap Metal/Mattress/Solid Waste
The main function of the two shaft scrap metal shredder crusher is to squeeze large pieces of material and large diameter drums of metal materials transported through the front cut of the shredder into sheet materials that meet the requirements. Large metal shredder not only improves the production capacity and crushing efficiency, but also expands the scope of application, metal shredder products make full use of impact, shear, mutual impact, grinding and other theories. It can process wallpaper, paper tube and other raw materials into fragments at one time, with less investment, low energy consumption, high productivity, good economic benefits, convenient use and maintenance. The crusher is mainly composed of a chip cutting device, a crushing device and a fan. The mill is equipped with a small particle size after cutting, and can be sent to the crushing device for further crushing without drying, and the powder fiber finished after crushing is sent to the aggregate site by the fan.
Product Parameters
| Model | Blade thickness(mm) | Blade diameter(mm) | Crushing chamber size (mm) | Capacity(t/h) | Power(kw) | Overall size(m) | Weight(kg) |
|---|---|---|---|---|---|---|---|
| 600 | 15-30 | 260 | 600*550 | 0.3-5 | 18.5*2 | 3*2*1.1 | 2850 |
| 800 | 15-40 | 300 | 800*600 | 0.5-6 | 22*2 | 3.3*2*2.42 | 4200 |
| 1000 | 15-40 | 350 | 1000*700 | 1-15 | 30*2 | 3.5*2*2.82 | 6500 |
| 1200 | 30-50 | 400 | 1200*800 | 1.5-20 | 37*2 | 3.8*2*2.82 | 7800 |
| 1400 | 30-60 | 450 | 1400*900 | 2-25 | 55*2 | 4.4*2*3 | 9600 |
| 1600 | 40-60 | 600 | 1600*1000 | 3-35 | 75*2 | 4.7*2*3.1 | 12560 |
Technical characteristics
- Heavy moving blade, high crushing power, the blade is made of wear-resistant steel, strong wear resistance, long service life.
- It is driven by decelerating motor, with strong power, low speed, large torque, low noise, time-saving and labor-saving.
- The product belongs to the fully automated equipment, set up start, stop, reverse and overload automatic reverse control functions, the use of complete functions, convenient and fast.
- The blade arrangement and bite mode are designed for metal, and the thickness of props and the number of claws can be changed according to different materials.
- Easy to adjust, low maintenance cost, uniform discharge, long use time.
